1. Grounding cable
4. M4x6 DIN 7984
Technical manual
5. Disconnect all the cables that are connected to the Patient position
control PCB.
2. Patient position control PCB
5. Patient support arm lower
cover
6. Install the new PCB in the reverse order
6 Patient support arm
3. PPC bridges
6. M4x6 DIN 7991
Planmeca ProMax 3D Max
177
