1. Focal spot
3. Source to image distance (SID)
1. Focal spot
3. Source to image distance (SID)
1.6 CTDI values (96 kV tube)
Technical manual
The following dose information is measured in a dosimetry phantom (head
phantom) that is compatible with the specification in international standard
IEC 60601-2-44 chapter 29.1.102.2.
The phantom is a cylinder (diameter = height = 160 mm) made of PMMA.
Holes have been drilled into the phantom, parallel to the axis of the cylinder.
Inside these holes a dose meter can be inserted. Holes which are not being
used for measurement are filled with rods made of the same material.
1 General and technical data
2. Source to object distance (SOD)
4. Imaging plane
2. Panoramic image layer
4. Imaging plane
Planmeca ProMax 3D Max
19
