3 Help and error messages
Error Explanation
code
E285
E286
E287
E290 Rotating tube head in
wrong position
E291 Collimator
E292
E293
E294
E295
E296
E297

3.2.2 X-ray generation related errors (E3xx)

Error Explanation
code
E301 Filament voltage
E302
E303
E311 Tube voltage
E312
82 Planmeca ProMax 3D Max
Timeout in collimator Y2 lower motor
which is connected to CAM PCB J25
and controlled by MCM module 7.
Timeout in tube head rotation motor
which is connected to CAM PCB J31
and controlled by MCM module 8.
Timeout in lift motor during patient
support vertical movement.
Rotating tube head in wrong position.
Collimator right X self test failed.
Collimator left X self test failed.
Collimator upper Y self test failed.
Collimator lower Y self test failed.
Collimator filter revolver self test failed.
Collimator X collision detected.
Collimator Y collision detected.
The following table lists the X-ray generation related errors.
Filament voltage missing completely.
Filament voltage too low during
preheat.
Filament voltage too high during
preheat.
Tube voltage missing completely.
Tube voltage too low.
Comments
Check the sensors,
cables and the motor.
Check the sensors,
cables and the motor.
Check the
adjustments and the
movement area.
Comments
Exposure not
possible. Check the
cabling, interfaces
and PSU- PCB and
tube head.
Exposure not
possible. Check the
cabling, interfaces
and PSU- PCB and
tube head.
Exposure not
possible. Check the
tube head and the
PSU-PCB.
Exposure interrupted.
Exposure not
possible. Check the
tube head and the
PSU PCB.
