3 Help and error messages

3.2.1 Motorised motion related errors (E2xx)

Error Explanation
code
E210 Open circuit in
E211
E212
E213
E214 Open circuit in
E215
E216
E217
E218
E219
E220
E221
E222
E223
78 Planmeca ProMax 3D Max
An error message indicates that the X-ray unit has a problem that needs to
be solved before further exposures can be taken. The X-ray unit will not
accept any commands from the user until the error message is cleared from
the touch screen.
The following table lists the motorised motion related errors.
Open circuit in lift motor which is
connected to PSU PCB J10.
Open circuit in shoulder motor which is
connected to PSU PCB J7 and
controlled by MCM module 1.
Open circuit in elbow motor which is
connected to PSU PCB J7 and
controlled by MCM module 2.
Open circuit in temple rest motor which
is connected to PPC PCB J5 and
controlled by MCM module 3.
Open circuit in scanning cephalostat
motor which is connected to CEPH
PCB J2 and controlled by MCM module
3.
Open circuit in patient support motor
which is connected to CPU PCB J20
and controlled by MCM module 3.
Open circuit in c-arm motor which is
connected to CAM PCB J21 and
controlled by MCM module 4.
Open circuit in collimator Y1 upper
motor which is connected to CAM PCB
J23 and controlled by MCM module 5.
Open circuit in collimator X motor which
is connected to CAM PCB J24 and
controlled by MCM module 5.
Open circuit in collimator X1 right motor
which is connected to CAM PCB J24
and controlled by MCM module 5.
Open circuit in collimator Y motor which
is connected to CAM PCB J25 and
controlled by MCM module 5.
Open circuit in tube head rotation motor
which is connected to CAM PCB J22
and controlled by MCM module 6.
Open circuit in collimator filter revolver
motor which is connected to CAM PCB
J22 and controlled by MCM module 6.
Open circuit in collimator filter motor
which is connected to CAM PCB J20
and controlled by MCM module 7.
Comments
Check the motor,
interface and cable.
Check the motor,
interface and cable.
Check the motor,
interface and cable.
Check the motor,
interface and cable.
Check the motor,
interface and cable.
Check the motor,
interface and cable.
Check the motor,
interface and cable.
Check the motor,
interface and cable.
Check the motor,
interface and cable.
Check the motor,
interface and cable.
Check the motor,
interface and cable.
Check the motor,
interface and cable.
Check the motor,
interface and cable.
Check the motor,
interface and cable.
