2.6 Diagnostics and troubleshooting

2.6.1 Showing component information

About this task
Steps
Technical manual
2.c. Select Set Exhibition Mode (3430) to activate the exhibition mode.
The exhibition mode allows you to demonstrate all the Planmeca
ProMax X-ray programs.
When this option is selected no X-ray radiation is generated when
you press the exposure button.
The programs can be selected and the C-arm will move normally
but no radiation will be generated and no radiation warning signals
will be given, i.e. this is a "dummy run" function for training and
demonstration purposes.
Accept or reject the mode change:
If you touch green check mark ProFace images can be taken
when the X-ray unit is connected to the PC.
If you touch the red cross mark you can drive the ProFace
exposure movement but an image is not taken.
With the Show Component Information you can list the component SW and
HW versions.
NOTE
The information available depends on the components the X-ray unit is
equipped with (e.g. sensors).
1. Touch the service spanner on the main display.
2. Touch the About tab.
3. Select the Component Information (4100).
2 User interface
Planmeca ProMax 3D Max 63
