UART SERIAL INTERFACE
UART and Power-Down Modes
Complete ongoing UART transfers before powering down the chip
into hibernate mode. Alternatively, disable the UART by clearing the
COMDIV register to 0x0000 before placing the device into hiberna-
tion. If hibernate mode is selected while a UART transfer is on,
the transfer does not continue on a return from hibernation. All the
intermediate data, states, and status logic in the UART are cleared.
Table 319. Registers Retained Through Hibernate Mode
Register
COMIEN
COMLCR
COMFCR
COMFBR
COMDIV
COMLCR2
COMCTL
COMRSC
Recommendations for UART Receive Wake-Up
from Hibernate Mode
If the UART receive input is used to wake the ADuCM356 from
hibernate mode, keep in mind that the UART block, along with
the rest of the ADuCM356 chip, requires 10 μs settling time after
the first falling edge of the UART wake-up byte. This delay means
that the first UART receive byte may not be read correctly by the
ADuCM356, especially with UART baud rates ≥ 57,600.
For reliable exit of hibernate mode via the UART receive pin,
perform one of the two following actions:
Ensure that the wake-up character received by the ADuCM356 is
►
a break byte. On receiving a break byte, the ADuCM356 UART
sets the break indicator status flag in the COMLSR, Bit 4 register.
This flag generates an interrupt.
Pull the ADuCM356 low for a period ≤1 μs. This setting triggers
►
the UART wake-up. After ≥10 μs, normal UART communications
can proceed.
analog.com
Affected Bits
ELSI, ERBFI
BRK, SP, EPS, PEN, WLS
RFTRIG, FDMAMD, FIFOEN
FBEN, DIVM, DIVN
DIV
OSR
RXINV, FORCECLKON
DISTX, DISRX, OENSP, OENP
However, the transmit pad (UART_SOUT) remains active in the
hibernate mode while transmitting. After hibernation, the UART can
be enabled by setting the COMDIV register, if previously cleared. If
DMA mode is needed, COMIEN, Bits[5:4] must be configured.
Table 319 details registers retained through hibernate mode. All
other registers and internal logic are cleared by a hardware default
value.
