SLEEP AND WAKE-UP TIMER
Address: 0x400C0820, Reset: 0xFFFF, Name: SEQ1SLEEPL
Address: 0x400C0830, Reset: 0xFFFF, Name: SEQ2SLEEPL
Address: 0x400C0840, Reset: 0xFFFF, Name: SEQ3SLEEPL
The SEQxSLEEPL registers define the device active time for SEQ0 to SEQ3. The counter is 20 bits. These registers set the 16 LSBs.
Table 185. Bit Descriptions for SEQxSLEEPL Registers
Bits Bit Name
[15:0] SLEEPTIME0[15:0]
Sequence 0 to Sequence 3 Sleep Time Registers (MSB)
Address: 0x400C0814, Reset: 0x000F, Name: SEQ0SLEEPH
Address: 0x400C0824, Reset: 0x000F, Name: SEQ1SLEEPH
Address: 0x400C0834, Reset: 0x000F, Name: SEQ2SLEEPH
Address: 0x400C0844, Reset: 0x000F, Name: SEQ3SLEEPH
The SEQxSLEEPH registers define the device active time for SEQ0 to SEQ3. The counter is 20 bits. These registers set the four MSBs.
Table 186. Bit Descriptions for SEQxSLEEPH Registers
Bits Bit Name
[15:4] Reserved
[3:0] SLEEPTIME0[19:16]
Timer Wake-Up Configuration Register
Address: 0x400C0A1C, Reset: 0x0000, Name: TMRCON
Table 187. Bit Descriptions for TMRCON Register
Bits Bit Name Settings
[15:1] Reserved
0 TMRINTEN
analog.com
Description
Sequence and Active Period. This register defines the length of time in which the device stays in active mode.
When this time elapses, the device returns to a sleep state.
Description
Reserved.
Sequence and Active Period. These bits define the length of time in which the device stays in active mode.
When this time elapses, the device returns to a sleep state.
Description
Reserved.
Wake-Up Timer Enable. Set this bit before entering hibernate mode to enable the ability of the sleep and
wake-up timer to wake up the chip.
0 Wake-up timer disabled.
1 Wake-up timer enabled.
ADuCM356
Reset Access
0xFFFF R/W
Reset Access
0x0 R
0xF R/W
Reset Access
0x0 R
0x0 R/W
Rev. A | 147 of 312
