REGISTER DETAILS: CLOCK ARCHITECTURE

CLOCK DIVIDERS REGISTER

Address: 0x4004C304, Reset: 0x00100404, Name: CTL1
The clock dividers register is used to set the divide rates for the HCLK, PCLK, and ACLK dividers. This register can be written to at any time. All
unused bits are read only, returning a value of 0. Writing to unused bits has no effect.
Table 8. Bit Descriptions for CTL1
Bits Bit Name Settings
[31:24] Reserved
[23:16] ACLKDIVCNT
[15:14] Reserved
[13:8] PCLKDIVCNT
[7:6] Reserved
[5:0] HCLKDIVCNT

USER CLOCK GATING CONTROL REGISTER

Address: 0x4004C314, Reset: 0x0000001F, Name: CTL5
User clock gating control is used to control the clock gating to peripherals.
Table 9. Bit Descriptions for CTL5
Bits Bit Name Settings
[31:6] Reserved
5 PERCLKOFF
4 GPIOCLKOFF
analog.com
Description
Reserved.
ACLK Clock Divider. This bit determines the ACLK rate based on the equation ACLK = root
clock/ACLKDIVCNT. For example, if the root clock is 26 MHz and ACLKDIVCNT = 0x1, ACLK
operates at 26 MHz. The value of ACLKDIVCNT takes effect after a write access to this register and
typically takes one ACLK cycle. This register can be read at any time and can be written to at any
time. The value range is from 1 to 32. Values larger than 32 are saturated to 32. Value 0 and Value
1 have the same results as divided by 1. The default value of this register is configured such that
ACLK = 1.625 MHz.
Reserved.
PCLK Clock Divider. Determines the PCLK rate based on the equation PCLK = root clock/
PCLKDIVCNT. For example, if the root clock is 26 MHz and PCLKDIVCNT = 0x2, PCLK operates
at 13 MHz. The value of PCLKDIVCNT takes effect after a write access to this register and typically
takes 2 to 4 PCLK cycles. This register can be read at any time and can be written to at any time.
The value range is from 1 to 32. Values larger than 32 are saturated to 32. Value 0 and Value 1
have the same results as divided by 1. The default value of this register is configured such that
PCLK frequency = 6.5 MHz. It is recommended to only use the 0x1, 0x2, or 0x4 value and matching
PCLKDIVCNT with HCLKDIVCNT.
Reserved.
HCLK Divide Count. Determines the HCLK rate based on the equation: HCLK = root clock/
HCLKDIVCNT. For example, if the root clock is 26 MHz and HCLKDIVCNT = 0x1, HCLK operates
at 26 MHz. The value of HCLKDIVCNT takes effect after a write access to this register and typically
takes 2 to 4 PCLK cycles (not HCLK cycles). This register can be read at any time and can be
written to at any time. The value range is from 1 to 32. Values larger than 32 are saturated to 32.
Value 0 and Value 1 have the same results as divided by 1. The default value of this register is
configured such that HCLK = 6.5 MHz. It is recommended to only use the values 0x1, 0x2, or 0x4
and match HCLKDIVCNT with PCLKDIVCNT.
Description
Reserved.
Peripheral Clocks Off. This bit is used to disable all clocks connected to all peripherals. After setting
this bit, any read or write to any of the peripheral registers automatically resets PERCLKOFF to 0, and
that read or write transaction is honored. After setting PERCLKOFF = 1, if the user reads the CTL5
register, PERCLKOFF is automatically cleared and PERCLKOFF reads as 0. The user must ensure
that DMA transactions are done and no more transactions are expected from the DMA. Ensure that
the PERCLKOFF bit write is the last write and no writes or reads to any of peripheral registers are
performed after setting this bit. Otherwise, the PERCLKOFF bit clears.
0 Clocks to all peripherals are active.
1 Clocks to all peripherals are gated off.
GPIO Clock Control. This bit disables the GPIO clock and controls the gate on the ACLK out from
ACLK divider. This ACLK control is available in active mode and Flexi
ACLK is always off and this bit has no effect. This bit does not automatically clear. Explicitly enable or
ADuCM356
Reset
0x0
0x10
0x0
0x4
0x0
0x4
Reset
0x0
0x0
0x1
™
mode. In hibernate mode, the
Rev. A | 17 of 312
Access
R
R/W
R
R/W
R
R/W
Access
R
R/W
R/W
