REGISTER SUMMARY: PROGRAMMABLE SWITCHES

The status of all the switches can be read from the switch sta-
tus registers at any time. These statuses indicate whether each
Table 143. Programmable Switch Matrix Register Summary
Address Name
0x400C200C SWCON
0x400C2150 DSWFULLCON
0x400C2154 NSWFULLCON
0x400C2158 PSWFULLCON
0x400C215C TSWFULLCON
0x400C21B0 DSWSTA
0x400C21B4 PSWSTA
0x400C21B8 NSWSTA
0x400C21BC TSWSTA
analog.com
switch is open or closed. The switch status registers are DSWSTA,
PSWSTA, NSWSTA, and TSWSTA.
Description
Switch matrix configuration
Dx switch matrix full configuration
Nx switch matrix full configuration
Px switch matrix full configuration
Tx switch matrix full configuration
Dx switch matrix status
Px switch matrix status
Nx switch matrix status
Tx switch matrix status
ADuCM356
Reset Access
0x0000FFFF R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
