REGISTER DETAILS: DMA
Table 201. Bit Descriptions for SWREQ
Bits Bit Name Settings
[31:24] Reserved
[23:0] CHAN

CHANNEL REQUEST MASK SET REGISTER

Address: 0x40010020, Reset: 0x00000000, Name: RMSK_SET
Table 202. Bit Descriptions for RMSK_SET
Bits Bit Name Settings
[31:24] Reserved
[23:0] CHAN

CHANNEL REQUEST MASK CLEAR REGISTER

Address: 0x40010024, Reset: 0x00000000, Name: RMSK_CLR
Table 203. Bit Descriptions for RMSK_CLR
Bits Bit Name Settings
[31:24] Reserved
[23:0] CHAN

CHANNEL ENABLE SET REGISTER

Address: 0x40010028, Reset: 0x00000000, Name: EN_SET
Table 204. Bit Descriptions for EN_SET
Bits Bit Name Settings
[31:24] Reserved
[23:0] CHAN
analog.com
Description
Reserved.
Generate Software Request. Set the appropriate bit to generate a software DMA request on the
corresponding DMA channel. Bit 0 corresponds to DMA Channel 0. Bit M − 1 corresponds to the
DMA Channel M – 1. These bits are automatically cleared by the hardware after the corresponding
software request completes.
0 DMA request is not created for Channel C.
1 DMA request is created for Channel C.
Description
Reserved.
Mask Requests from DMA Channels. This register disables DMA requests from peripherals. Each
bit of the register represents the corresponding channel number in the DMA controller. Set the
appropriate bit to mask the request from the corresponding DMA channel. Bit 0 corresponds to
DMA Channel 0. Bit M – 1 corresponds to DMA Channel M – 1.
0 When read as 0, requests are enabled for Channel C. When written as 0, no effect.
1 When read as 1, requests are disabled for Channel C. When written as 1, peripherals associated
with Channel C are disabled from generating DMA requests.
Description
Reserved.
Clear Request Mask Set Bits. This register enables DMA requests from peripherals by clearing the
mask set in the RMSK_SET register. Each bit of the register represents the corresponding channel
number in the DMA controller. Set the appropriate bit to clear the corresponding bit in RMSK_SET,
Bits[23:0]. Bit 0 corresponds to DMA Channel 0. Bit M – 1 corresponds to DMA Channel M – 1.
0 No effect. Use the RMSK_SET register to disable DMA requests.
1 Peripherals associated with Channel C are enabled to generate DMA requests.
Description
Reserved.
Enable DMA Channels. This register allows the enabling of DMA channels. Reading the register
returns the enable status of the channels. Each bit of the register represents the corresponding
channel number in the DMA controller. Set the appropriate bit to enable the corresponding channel.
Bit 0 corresponds to DMA Channel 0. Bit M – 1 corresponds to DMA Channel M – 1.
0 When read as 0, Channel C is disabled. When written as 0, no effect. Use the EN_CLR register to
disable this channel.
1 When read as 1, Channel C is enabled. When written as 1, Channel C is enabled.
ADuCM356
Reset Access
0x00 R
0x000000 W
Reset Access
0x00 R
0x000000 R/W
Reset Access
0x00 R
0x000000 W
Reset Access
0x00 R
0x000000 R/W
Rev. A | 172 of 312
