Reference Manual
REGISTER DETAILS: ANALOG DIE GENERAL-PURPOSE TIMERS
Table 355. Bit Descriptions for CON0 (Continued)
Bits
Bit Name
Settings
2
UP
[1:0]
PRE

CLEAR INTERRUPT REGISTER

Address: 0x400C0D0C, Reset: 0x0000, Name: CLRI0
Table 356. Bit Descriptions for CLRI0
Bits
Bit Name
Settings
[15:2]
Reserved
1
CAP
0
TMOUT

16-BIT LOAD VALUE, ASYNCHRONOUS REGISTER

Address: 0x400C0D14, Reset: 0x0000, Name: ALD0
Only use when a synchronous clock source is selected (CON0, Bits[6:5] = 00).
Table 357. Bit Descriptions for ALD0
Bits
Bit Name
Settings
[15:0]
ALOAD

16-BIT TIMER VALUE, ASYNCHRONOUS REGISTER

Address: 0x400C0D18, Reset: 0x0000, Name: AVAL0
Only use when a synchronous clock source is selected (CON0, Bits[6:5] = 00).
Table 358. Bit Descriptions for AVAL0
Bits
Bit Name
Settings
[15:0]
AVAL

STATUS REGISTER

Address: 0x400C0D1C, Reset: 0x0000, Name: STA0
analog.com
Description
Count Up. Used to control whether the timer increments (counts up) or decrements (counts down) the up
or down counter.
1 Timer is set to count up.
0 Timer is set to count down. Default.
Prescaler. Controls the prescaler division factor applied to the selected clock of the timer.
00 Source clock/1 or source clock/4. When CON0, Bit 15 is set, source is source clock/1. When cleared, the
source is source clock/4.
01 Source clock/16.
10 Source clock/64.
11 Source clock/256.
Description
Reserved.
Clear Captured Event Interrupt. This bit is used to clear a capture event interrupt.
1 Clear the capture event interrupt.
0 No effect.
Clear Timeout Interrupt. This bit is used to clear a timeout interrupt.
1 Clears the timeout interrupt.
0 No effect.
Description
Load Value, Asynchronous. The up or down counter is periodically loaded with this value if periodic mode
is selected (CON0, Bit 3 = 1). Writing ALOAD takes advantage of having the timer run on PCLK by
bypassing clock synchronization logic that is otherwise required.
Description
Counter Value. Reflects the current up or down counter value. Reading AVAL takes advantage of having
the timer run on PCLK by bypassing clock synchronization logic that is otherwise required.
ADuCM356
Reset
Access
0x0
R/W
0x2
R/W
Reset
Access
0x0
R
0x0
W1C
0x0
W1C
Reset
Access
0x0
R/W
Reset
Access
0x0
R
Rev. A | 275 of 312
