REGISTER DETAILS: ADC CIRCUIT
Table 71. Bit Descriptions for ADCINTSTA (Continued)
Bits Bit Name
4 ADCMINERR
3 TEMPRDY
2 SINC2RDY
1 DFTRDY
0 ADCRDY

AFE DSP CONFIGURATION REGISTER

Address: 0x400C20D0, Reset: 0x00000090, Name: DFTCON
Table 72. Bit Descriptions for DFTCON
Bits Bit Name Settings
[31:22] Reserved
[21:20] DFTINSEL
[19:8] Reserved
[7:4] DFTNUM
analog.com
Settings Description
1 Interrupt asserted. When set, indicates that ADCDAT result was greater than the value specified
by the ADCMAX register. This bit generates an interrupt if ADCINTIEN, Bit 5 = 1. User must
write 1 to this bit to clear it. Writing 0 has no effect.
ADC Minimum Value Check Fail. Writing 0 has no effect.
0 Interrupt not asserted.
1 Interrupt asserted. When set, indicates ADCDAT result was less than the value specified by
ADCMIN. This bit generates an interrupt if ADCINTIEN, Bit 4 = 1.
Temperature Sensor Result Ready Interrupt. User must write 1 to this bit to clear it. Writing 0 has
no effect.
0 Interrupt not asserted.
1 Interrupt asserted. When set, indicates TEMPSENSDAT0 result is ready for reading. This bit
generates an interrupt if ADCINTIEN, Bit 3 = 1.
Low-Pass Filter Result Status. Supply rejection filter result ready interrupt. User must write 1 to
this bit to clear it. Writing 0 has no effect.
0 Interrupt not asserted.
1 Interrupt asserted. When set, indicates SINC2DAT result is ready for reading. This bit generates
an interrupt if ADCINTIEN, Bit 2 = 1.
DFT Result Ready Status. DFT result ready interrupt. User must write 1 to this bit to clear it.
Writing 0 has no effect.
0 Interrupt not asserted.
1 Interrupt asserted. When set, indicates DFTREAL and DFTIMAG registers are ready for reading.
This bit generates an interrupt if ADCINTIEN, Bit 1 = 1.
ADC Result Ready Status. ADC result ready interrupt. User must write 1 to this bit to clear it.
Writing 0 has no effect.
0 Interrupt not asserted.
1 Interrupt asserted. When set, indicates ADCDAT register is ready for reading. This bit generates
an interrupt if ADCINTIEN, Bit 0 = 1.
Description
Reserved.
DFT Input Select. ADCFILTERCON, Bit 7 is the highest priority. If ADCFILTERCON, Bit 7 is 1, output
of average block is used as the DFT input, regardless of the DFTINSEL setting.
00 Supply filter output. Select output from low-pass supply filter.
01 Gain offset output with or without sinc3. Select output from ADC gain and offset correction stage. If
ADCFILTERCON, Bit 6 is 1 (filter is bypassed), ADC raw data through gain or offset correction is the
DFT input. If the SINC3BYP bit in the ADCFILTERCON register is 0 (filter is not bypassed), the sinc3
output through gain or offset correction is the DFT input.
10 ADC raw data. Select output direct from the ADC, no offset or gain correction. Only supported for 800
kHz sample rate of ADC.
11 Supply filter output. Select output from low-pass supply filter. Same as 00.
Reserved.
ADC Samples Used. DFT number is 4 to 16,384.
0 DFT point number is 4. DFT uses 4 ADC samples.
1 DFT point number is 8. DFT uses 8 ADC samples.
10 DFT point number is 16. DFT uses 16 ADC samples.
11 DFT point number is 32. DFT uses 32 ADC samples.
ADuCM356
Reset Access
0x0 R/W1C
0x0 R/W1C
0x0 R/W1C
0x0 R/W1C
0x0 R/W1C
Reset Access
0x0 R
0x0 R/W
0x0 R
0x9 R/W
Rev. A | 68 of 312
