Tx Switch Matrix Status Register - Analog Devices ADuCM356 Reference Manual

Reference Manual
REGISTER DETAILS: PROGRAMMABLE SWITCHES
Table 151. Bit Descriptions for NSWSTA (Continued)
Bits Bit Name
1 N2STA
0 N1STA

TX SWITCH MATRIX STATUS REGISTER

Address: 0x400C21BC, Reset: 0x00000000, Name: TSWSTA
This register gives the status of the Tx switches shown in
Table 152. Bit Descriptions for TSWSTA
Bits Bit Name
[31:12] Reserved
11 TR1STA
10 T11STA
9 T10STA
8 T9STA
7 T8STA
6 T7STA
5 T6STA
4 T5STA
3 T4STA
2 T3STA
1 T2STA
analog.com
Settings Description
0 Switch open.
1 Switch closed.
Status of N2 Switch.
0 Switch open.
1 Switch closed.
Status of N1 Switch.
0 Switch open.
1 Switch closed.
Figure 27.
Settings Description
Reserved.
Status of TR1 Switch.
0 Switch open.
1 Switch closed.
Status of T11 Switch.
0 Switch open.
1 Switch closed.
Status of T10 Switch.
0 Switch open.
1 Switch closed.
Status of T9 Switch.
0 Switch open.
1 Switch closed.
Status of T8 Switch.
0 Switch open.
1 Switch closed.
Status of T7 Switch.
0 Switch open.
1 Switch closed.
Status of T6 Switch.
0 Switch open.
1 Switch closed.
Status of T5 Switch.
0 Switch open.
1 Switch closed.
Status of T4 Switch.
0 Switch open.
1 Switch closed.
Status of T3 Switch.
0 Switch open.
1 Switch closed.
Status of T2 Switch.
ADuCM356
Reset Access
0x0 R
0x0 R
Reset Access
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
Rev. A | 125 of 312
