REGISTER SUMMARY: FLASH CACHE CONTROLLER

Table 223. FLCC Register Summary
Address Name
0x40018000 STAT
0x40018004 IEN
0x40018008 CMD
0x4001800C KH_ADDR
0x40018010 KH_DATA0
0x40018014 KH_DATA1
0x40018018 PAGE_ADDR0
0x4001801C PAGE_ADDR1
0x40018020 KEY
0x40018024 WR_ABORT_ADDR
0x40018028 WRPROT
0x4001802C SIGNATURE
0x40018030 UCFG
0x4001803C ABORT_EN_LO
0x40018040 ABORT_EN_HI
0x40018044 ECC_CFG
0x40018048 ECC_ADDR
0x40018050 ADI_POR_SEC
analog.com
Description
Status
Interrupt enable
Command
Write address
Write lower data
Write upper data
Lower page address
Upper page address
Key
Write abort address
Write protection
Signature
User configuration
IRQ abort enable (lower bits)
IRQ abort enable (upper bits)
ECC configuration
ECC status (address)
Analog Devices flash security
ADuCM356
Reset Access
0x00000000 R/W
0x40 R/W
0x00000000 R/W
0x00000000 R/W
0xFFFFFFFF R/W
0xFFFFFFFF R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 W
0xXXXXXXXX R
0xFFFFFFFF R/W
0xXXXXXXXX R
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000002 R/W
0x00000000 R
0x00000000 R/W
