REGISTER SUMMARY: CLOCK ARCHITECTURE
Table 3. Digital Die System Clock Register Summary (CLKG0_CLK Stack)
Address
Name
0x4004C10C
KEY
0x4004C110
CTL
0x4004C300
CTL0
0x4004C304
CTL1
0x4004C314
CTL5
0x4004C318
STAT0
Table 4. Analog Die Clock Register Summary (AFECON Stack)
Address
Name
0x400C0408
CLKCON0
0x400C0410
CLKEN1
0x400C0414
CLKSEL
0x400C041C
GPIOCLKMUXSEL
0x400C0420
CLKCON0KEY
0x400C0A70
CLKEN0
0x400C0A0C
OSCKEY
0x400C0A10
OSCCON
0x400C20BC
HPOSCCON
0x400C22F0
PMBW
analog.com
Description
Key protection for CTL register
Oscillator control
Clock Control 0
Clock dividers
User clock gating control
Clocking status
Description
Clock divider configuration
Clock gate enable
Clock select
GPIO clock mux select to GPIO1 pin
Key protection for CLKCON0
Clock control of low-power TIA chop, watchdog, and wake-up timers
Key protection for OSCCON
Oscillator control
High-power oscillator configuration
Power mode configuration register
ADuCM356
Reset
Access
0x00000000
R/W
0x00000302
R/W
0x00000078
R/W
0x00100404
R/W
0x0000001F
R/W
0x00000000
R/W
Reset
0x0441
0x010A
0x0000
0x0000
0x0000
0x0000
0x0000
0x0303
0x00000024
0x00000000
Rev. A | 15 of 312
Access
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
