ADuCM4050 EZ-KIT
Manual
Revision 1.0, December 2016
Part Number
82-000802-01
Analog Devices, Inc.
One Technology Way
Norwood, MA 02062-9106

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADuCM4050 EZ-KIT and is the answer not in the manual?

Questions and answers

Related Manuals for Analog Devices ADuCM4050 EZ-KIT

Summary of Contents for Analog Devices ADuCM4050 EZ-KIT

  • Page 1 ® ADuCM4050 EZ-KIT Manual Revision 1.0, December 2016 Part Number 82-000802-01 Analog Devices, Inc. One Technology Way Norwood, MA 02062-9106...
  • Page 2 Regulatory Compliance The ADuCM4050 EZ-KIT is designed to be used solely in a laboratory environment. The board is not intended for use as a consumer-end product or as a portion of a consumer-end product. The board is an open system design, which does not include a shielded enclosure and, therefore, may cause interference to other electrical devices in close proximity.
  • Page 3 The ADuCM4050 EZ-KIT contains ESD (electrostatic discharge) sensitive devices. Electrostatic charges readily accu- mulate on the human body and equipment and can discharge without detection. Permanent damage may occur on devices subjected to high-energy discharges. Proper ESD precautions are recommended to avoid performance degra- dation or loss of functionality.

  • Page 4: Table Of Contents

    Manual Contents ............................1–2 Technical Support ............................1–2 Supported Processors ............................. 1–3 Supported Tools............................. 1–3 Product Information ............................1–3 Analog Devices Website..........................1–3 EngineerZone ............................. 1–4 Notation Conventions ........................... 1–4 Using the Board Product Overview ............................2–1 Package Contents............................2–2 Default Configuration ...........................
  • Page 5 Power Source Select ( JP13 ) ........................3–8 mbed Power Enable ( JP18 ) ........................3–8 RF Config Select ( JP19 ).......................... 3–8 LEDs ................................3–8 Reset ( LED1 )............................3–10 Power ( LED2 ) ............................3–10 ® ADuCM4050 EZ-KIT Manual...
  • Page 6 DEBUG ( P10 ) .......................... 3–15 mbed USB ( P11 ) ..........................3–15 Battery ( J8 and J9 )..........................3–15 PV Cell ( J3 )............................3–16 Clock ( J1-2 ) ............................3–16 Arduino Interface ( J4-7 )........................3–16 ® ADuCM4050 EZ-KIT Manual...

  • Page 7: Preface

    Preface 1 Preface Thank you for purchasing the Analog Devices, Inc. ADuCM4050 EZ-KIT evaluation system. The ADuCM4050 processor is an ultra low-power integrated mixed-signal microcontroller system for processing, control and connectivity. The MCU system is based on the ARM Cortex-M4F processor. The MCU also has a col- lection of digital peripherals, embedded SRAM and flash memory, and an analog subsystem which provides clock- ing, reset, and power management capability in addition to an ADC subsystem.

  • Page 8: Intended Audience

    ADuCM4050 family of processors is based on the ARM Cortex-M4 core. For additional information about the Analog Devices processor, see the Hardware Reference Manual. The document describes the core and memory architecture of the ADuCM4050 processor, but does not provide detailed program- ming information.

  • Page 9: Supported Processors

    Norwood, MA 02062-9106 Supported Processors This evaluation system supports the Analog Devices ADuCM4050 processor. Supported Tools Information about code development tools for the ADuCM4050 EZ-KIT and ADuCM4050 family of processors is available at: http://www.analog.com/ADuCM4050 Product Information Product information can be obtained from the Analog Devices Website Analog Devices Website The Analog Devices website, http://www.analog.com, provides information about a broad range of products - ana-...

  • Page 10: Engineerzone

    If you are a registered user, just log on. Your user name is your e-mail address. EngineerZone EngineerZone is a technical support forum from Analog Devices, Inc. It allows you direct access to ADI technical support engineers. You can search FAQs and technical information to get quick answers to your embedded process- ing and DSP design questions.
  • Page 11 A warning identifies conditions or inappropriate usage of the product that could lead to conditions that are potentially hazardous for devices users. In the online version of this book, the word ATTENTION: appears instead of this symbol. ® 1–5 ADuCM4050 EZ-KIT Manual...

  • Page 12: Using The Board

    This chapter provides information on the major components and peripherals on the board along with instructions for installing and setting up the emulation software. Product Overview The board features: • Analog Devices ADuCM4050 processor • 64-pin LFCSP package or 72-ball WLCSP package • 26 MHz oscillator • SPI Flash (SPI2) chip •...

  • Page 13: Package Contents

    • CE compliant • 5V @ 3.6 Amps • Power measurement • Jumpers for measuring processor and board current draw Package Contents Your ADuCM4050 EZ-KIT package contains the following items. • ADuCM4050 EZ-KIT (LFCSP/WLCSP) board 2–2 ® ADuCM4050 EZ-KIT Manual...

  • Page 14: Default Configuration

    • J-Link Lite emulator • 20 Pin flat cable • USB 2.0 Cable Contact the vendor where you purchased your ADuCM4050 EZ-KIT or contact Analog Devices, Inc. if any item is missing. Default Configuration The ADuCM4050 EZ-KIT board is designed to run as a standalone unit.
  • Page 15 Default Configuration LED6 JP12 JP11 JP10 JP19 JP15 JP16 JP14 JP13 JP17 LED7 JP18 Figure 2-1: Default Hardware Setup for ADuCM4050 WLCSP EZ-KIT 2–4 ® ADuCM4050 EZ-KIT Manual...

  • Page 16: Iar Embedded Workbench Setup

    Segger product and software download, go to: http://www.iar.com/en/Products/IAR-Embedded-Workbench. The ADuCM4050 EZ-KIT software, based on the IAR Embedded WorkBench, can be found at: http://www.analog.com/ADuCM4050 Follow these instructions to ensure correct operation of the product software and hardware. 1. Connect the EZ-KIT board to a personal computer (PC) running IAR Embedded WorkBench, using a J- Link/J-Trace emulator package: ®...

  • Page 17: Mbed Interface

    2. Choose File > Open > Workspace to open a workspace for the project to download and debug. 3. Choose Project > Options. The General Options, Target page appears. 4. In Processor variant, ensure Device is Analog Devices ADuCM4x50 5. Choose Debugger in the Category pane. The Debugger, Setup options page appears.

  • Page 18: Debug Interface

    Refer to the readme file provided with each example for more information. Reference Design Information A reference design info package is available for download on the Analog Devices Web site. The package provides information on the schematic design, layout, fabrication, and assembly of the board.

  • Page 19: 16-Bit Digital I 2 C Temperature Sensor (Adt7420)

    ADC input for synchronous conversion of an external signal. The entire system consumes less than 2 μA at a 100 Hz output data rate and 270 nA when in motion triggered wake-up mode. 2–8 ® ADuCM4050 EZ-KIT Manual...

  • Page 20: Usb To Uart (Ft232R)

    • FIFO receives and transmits buffers for high-data throughput • Device supplied pre-programmed with unique USB serial number • Supports bus powered, self-powered and high-power bus powered USB configurations • Integrated +3.3V level converter for USB I/O ® 2–9 ADuCM4050 EZ-KIT Manual...

  • Page 21: Adf7Xxx Wireless Transceiver Daughterboard Interface

    ADF7030 and ADF7030-1 wireless transceivers. These are low-power, high-performance, integrated radio transceiv- ers supporting a wide range of modulation schemes and channel widths in the sub-GHz and 2.4 GHz frequency ranges. "For more information about Analog Devices Transceiver offerings please visit : http://www.analog.com/en/prod- ucts/rf-microwave/integrated-transceivers-transmitters-receivers/low-power-rf-transceivers.html Arduino Interface The Arduino interface supports connecting with 3V shield boards, extending the evaluation system's capabilities.

  • Page 22: Hardware Reference

    Hardware Reference 3 Hardware Reference This chapter describes the hardware design of the ADuCM4050 EZ-KIT . System Architecture The board's configuration is shown in the Block Diagram figure. 32.768 crystal Temp SPI Flash crystal Sensor Accelerometer 128Mb ADT7420 Mini-B FT232RQ...

  • Page 23: Switches

    The pushbutton switch determines the boot mode of the processor. The Boot Mode Select Switch table shows the available boot mode settings. By default, the processor boots from the internal flash memory. To get in Boot mode 0, user must hold down pushbutton during power-up. 3–2 ® ADuCM4050 EZ-KIT Manual...

  • Page 24: Reset Pushbutton ( Sw2 )

    The GPIO pushbuttons are connected to the processor’s signals as follows: Push Button ADuCM4050 LFCSP EZ-KIT ADuCm4050 WLCSP EZ-KIT P2_09/GPIO41/ADC0_VIN6/ P2_09/GPIO41/ADC0_VIN6/ SPI0_CS3 SPI0_CS3 P2_06/GPIO38/ADC0_VIN3 P2_06/GPIO38/ADC0_VIN3 Jumpers This section describes functionality of the configuration jumpers. The Jumper Locations figure shows the jumper locations. ® 3–3 ADuCM4050 EZ-KIT Manual...
  • Page 25 Jumpers JP12 JP11 JP10 JP19 JP15 JP14 JP16 JP13 JP17 JP18 Figure 3-3: Jumper Locations for ADuCM4050 WLCSP EZ-KIT 3–4 ® ADuCM4050 EZ-KIT Manual...

  • Page 26: Main Power Select ( Jp12 )

    USB, or wall transformer. Refer to the Main Power Select Jumper table. The default setting is to power the board from the USB cable. Table 3-2: Main Power Select Jumper Position Power Source 1 and 3 Emulator 5V 3 and 4 USB 5V 3 and 5 Wall 5V ® 3–5 ADuCM4050 EZ-KIT Manual...

  • Page 27: Io Power Select ( Jp14 )

    To measure current draw of ADC peripheral block, remove jumper JP1 and measure voltage across R19. To measure current draw of analog peripheral block, remove jumper JP2 and measure voltage across R20. To measure current draw of digital peripheral block, remove jumper JP3 and measure voltage across R21. 3–6 ® ADuCM4050 EZ-KIT Manual...

  • Page 28: Remote Boot Select ( Jp7 )

    The RF power select jumper will connect theEZ-KIT 3V supply to the Wireless Transreceiver daughter card. Pin1 and Pin2 will be shorted by default. If a Wireless Transreceiver daughterboard is used and will have it's own power supply then Jumper between Pin1& Pin2 should be kept Open. ® 3–7 ADuCM4050 EZ-KIT Manual...

  • Page 29: Power Source Select ( Jp13 )

    TMR0_2 and TMR0_3 to RGB LED. Jumper should be installed only when ADF7xxx wireless module will be inserted on EZ-KIT. LEDs This section describes the on-board LEDs. The LED Locations figure shows the LED locations. 3–8 ® ADuCM4050 EZ-KIT Manual...
  • Page 30 LEDs LED6 LED7 Figure 3-5: LED Locations for ADuCM4050 WLCSP EZ-KIT ® 3–9 ADuCM4050 EZ-KIT Manual...

  • Page 31: Reset ( Led1 )

    Three LEDs are connected to the general-purpose I/O pins of the processor (see the GPIO LEDs table). The LEDs are active high and are ON (amber) by writing a 1 to the correct processor signal. 3–10 ® ADuCM4050 EZ-KIT Manual...

  • Page 32: Rgb ( Led6 )

    When ON (amber), it indicates that mbed CPU is out of reset state. Connection between host PC and mbed USB connector (P11) enables mbed CPU and activates mbed LED. Connectors This section describes connector functionality and provides information about mating connectors. The connector locations are shown in the Connector Locations figure. ® 3–11 ADuCM4050 EZ-KIT Manual...
  • Page 33 Connectors Figure 3-7: Connector Locations for ADuCM4050 WLCSP EZ-KIT 3–12 ® ADuCM4050 EZ-KIT Manual...

  • Page 34: Expansion Interface 3 ( P1A )

    This connector is located on the bottom side of the board. The connector expands the board's capabilities by providing an interface to EI3 daughterboards. Part Description Manufacturer Part Number 120-pin 0.6mm Hirose FX8-120P-SV1(91) Mating Connector 120-pin 0.6mm Hirose FX8-120S-SV(21) ® 3–13 ADuCM4050 EZ-KIT Manual...

  • Page 35: Adf7Xxx Wireless Transceiver Daughterboard Interface ( P1-3 )

    UART1_Tx and UART1_Rx are direct signals from processor. The P7 connector is a 0.1” 4 pin male header. UART interface GPIO details are as follows: UART Signal (P7) ADuCM4050 LFCSP EZ-KIT ADuCM4050 WLCSP EZ-KIT P1_15/GPIO31/SPT0_ACLK/ P2_12/GPIO44/UART1_TX/ UART1_Tx (P7-2) UART1_TX SPI2_CS3 P2_00/GPIO32/SPT0_AFS/ P2_13/GPIO45/UART1_RX/ UART1_Rx (P7-3) UART1_RX SPI0_CS2 3–14 ® ADuCM4050 EZ-KIT Manual...

  • Page 36: Power ( P8 )

    IO Power Select ( JP14 Table 3-8: J8 Connector Part Description Manufacturer Part Number Coincell Holder BS-3 Battery 3V 20mm Coin Panasonic CR2032 Table 3-9: J9 Connector Part Description Manufacturer Part Number AA Holder Keystone Electronics 2460 ® 3–15 ADuCM4050 EZ-KIT Manual...

  • Page 37: Pv Cell ( J3 )

    Manufacturer Part Number Battery 3.6V 2.6Ah AA Dantona Industries LS14500 PV Cell ( J3 ) This connector is used for interfacing with engery harvesting evaluation boards from Analog Devices. Part Description Manufacturer Part Number 8-pin 0.1" right angle Harwin M20-7880446...
  • Page 38 ® ADuCM4050 EZ-KIT Manual...
  • Page 39 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Analog Devices Inc. ADZS-U4050LF-EZKIT ADZS-U4050WL-EZKIT...
