SEQUENCER
Table 170. Bit Descriptions for SEQ1INFO Register
Bits Bit Name
[31:27] Reserved
[26:16] SEQ1INSTNUM
[15:11] Reserved
[10:0] SEQ1STARTADDR
Command and Data FIFO Internal Data Count Register
Address: 0x400C2200, Reset: 0x00000000, Name: FIFOCNTSTA
Table 171. Bit Descriptions for FIFOCNTSTA Register
Bits Bit Name
[31:27] Reserved
[26:16] DATAFIFOCNTSTA[10:0]
[15:0] Reserved
Trigger Sequence Register
Address: 0x400C0430, Reset: 0x0000, Name: TRIGSEQ
Table 172. Bit Descriptions for TRIGSEQ Register
Bits Bit Name
[15:4] Reserved
3 TRIG3
2 TRIG2
1 TRIG1
0 TRIG0
analog.com
Description
Reserved.
SEQ1 Instruction Number.
Reserved.
SEQ1 Start Address.
Description
Reserved.
Current Number of Words in the Data FIFO.
Reserved.
Description
Reserved.
Trigger Sequence 3.
Trigger Sequence 2.
Trigger Sequence 1.
Trigger Sequence 0.
ADuCM356
Reset Access
0x0 R
0x0 R/W
0x0 R
0x0 R/W
Reset Access
0x0 R
0x0 R
0x0 R
Reset Access
0x0 R
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/WS
