REGISTER SUMMARY: DIGITAL DIE WAKE-UP TIMER

Table 379. WUT Register Summary
Address
0x40001400
0x40001404
0x40001408
0x4000140C
0x40001410
0x40001414
0x40001418
0x40001420
0x40001428
0x4000142C
0x40001430
0x40001434
0x40001438
0x4000143C
0x40001440
0x40001444
0x40001488
analog.com
Name Description
CR0 Control 0
SR0 Status 0
SR1 Status 1
CNT0 Count 0
CNT1 Count 1
ALM0 Alarm 0
ALM1 Alarm 1
GWY Gateway
CR1 Control 1
SR2 Status 2
SNAP0 Snapshot 0
SNAP1 Snapshot 1
SNAP2 Snapshot 2
MOD Modulo
CNT2 Count 2
ALM2 Alarm 2
SR6 Status 6
ADuCM356
Reset Access
0x03C4 R/W
0x7F88 R/W
0x0078 R
0x0000 R/W
0x0000 R/W
0xFFFF R/W
0xFFFF R/W
0x0000 W
0x01E0 R/W
0xC000 R/W
0x0000 R
0x0000 R
0x0000 R
0x0040 R
0x0000 R
0x0000 R/W
0x7900 R
