REGISTER DETAILS: CLOCK ARCHITECTURE

KEY PROTECTION FOR CTL REGISTER

Address: 0x4004C10C, Reset: 0x00000000, Name: KEY
Table 5. Bit Descriptions for KEY
Bits Bit Name Settings
[31:16] Reserved
[15:0] VALUE 0xCB14 Oscillator Key. The CTL register is key protected. To unlock this protection, write 0xCB14 to KEY before

OSCILLATOR CONTROL REGISTER

Address: 0x4004C110, Reset: 0x00000302, Name: CTL
The CTL register is key protected. To unlock this protection, write 0xCB14 to KEY before writing to the CTL register. A write to any other register
on the Arm peripheral bus before writing to the CTL register returns the protection to the lock state.
Table 6. Bit Descriptions for CTL
Bits Bit Name Settings
[31:10] Reserved
9 HFOSCOK
8 LFOSCOK
[7:2] Reserved
1 HFOSCEN
0 Reserved

CLOCK CONTROL 0 REGISTER

Address: 0x4004C300, Reset: 0x00000078, Name: CTL0
The Clock Control 0 register is used to configure clock sources used by various systems, such as the core, memories, and peripherals. All
unused bits are read only and return a value of 0. Writing unused bits has no effect.
Table 7. Bit Descriptions for CTL0
Bits Bit Name Settings
[31:2] Reserved
[1:0] CLKMUX
01, 10 Reserved.
analog.com
Description
Reserved.
writing to CTL. A write to any other register on the Arm peripheral bus before writing to CTL returns the
protection to the lock state.
Description
Reserved.
Status of High Frequency Oscillator on Digital Die. This bit indicates when the oscillator is stable after it
is enabled. This bit is not a monitor and does not indicate a subsequent loss of stability.
0 Oscillator is not yet stable or is disabled.
1 Oscillator is enabled, stable, and ready for use.
Status of Low Frequency Oscillator on Digital Die. This bit indicates when the oscillator is stable after it is
enabled. This bit is not a monitor and does not indicate a subsequent loss of stability.
0 Oscillator is not yet stable or is disabled.
1 Oscillator is enabled, stable, and ready for use.
Reserved.
High Frequency Internal Oscillator Enable. This bit is used to enable and disable the high frequency
oscillator on the digital die. The oscillator must be stable before use. This bit must be set before the
SYSRESETREQ system reset can be initiated. SYSRESETREQ is a bit in the Arm Cortex-M3 AIRCR
register.
0 The high frequency oscillator is disabled and placed in a low-power state.
1 The high frequency oscillator is enabled.
Reserved. This bit must always be 0.
Description
Reserved.
Clock Mux Select. Determines which single shared clock source is used by the gated system clock
(peripheral clock (PCLK) on digital die) and high-speed clock (HCLK) dividers.
00 High frequency internal oscillator is selected.
11 External clock routed from analog die. Can be external crystal or clock source.
ADuCM356
Reset Access
0x0000 R
0x0000 W
Reset Access
0x0 R
0x1 R
0x1 R
0x0 R
0x1 R/W
0x0 R/W
Reset Access
0x0000000 R
0x0 R/W
Rev. A | 16 of 312
