REGISTER SUMMARY: ADC CIRCUIT

Table 58. ADC Control Register Summary
Address Name
0x400C21A8 ADCCON
0x400C2044 ADCFILTERCON
0x400C2074 ADCDAT
0x400C2078 DFTREAL
0x400C207C DFTIMAG
0x400C2080 SINC2DAT
0x400C2084 TEMPSENSDAT0
0x400C2088 ADCINTIEN
0x400C2098 ADCINTSTA
0x400C20D0 DFTCON
0x400C2174 TEMPCON0
0x400C2180 BUFSENCON
0x400C21F0 REPEATADCCNV
0x400C238C ADCBUFCON
Table 59. ADC Calibration Register Summary
Address Name
0x400C2230 CALDATLOCK
0x400C2288 ADCOFFSETLPTIA0
0x400C228C ADCGNLPTIA0
0x400C22C0 ADCOFFSETLPTIA1
0x400C22C4 ADCGNLPTIA1
0x400C2234 ADCOFFSETHSTIA
0x400C2284 ADCGNHSTIA
0x400C2244 ADCOFFSETGN1
0x400C2240 ADCGAINGN1
0x400C22CC ADCOFFSETGN1P5
0x400C2270 ADCGAINGN1P5
0x400C22C8 ADCOFFSETGN2
0x400C2274 ADCGAINGN2
0x400C22D4 ADCOFFSETGN4
0x400C2278 ADCGAINGN4
0x400C22D0 ADCOFFSETGN9
0x400C2298 ADCGAINGN9
0x400C223C ADCOFFSETTEMPSENS0
0x400C2238 ADCGAINTEMPSENS0
Table 60. ADC Digital Postprocessing Register Summary (Optional)
Address Name
0x400C20A8 ADCMIN
0x400C20AC ADCMINSM
0x400C20B0 ADCMAX
0x400C20B4 ADCMAXSMEN
0x400C20B8 ADCDELTA
Table 61. ADC Statistics Register Summary (Optional)
Address Name
0x400C21C4 STATSCON
0x400C21C8 STATSMEAN
analog.com
Description
ADC configuration register
ADC output filters configuration
Raw result
DFT result, real part
DFT result, imaginary part
Sinc2 and supply rejection filter result
Temperature Sensor 0 result
Analog capture interrupt enable
Analog capture interrupt
AFE DSP configuration
Temperature Sensor 0 configuration
High-power and low-power buffer control
Number of repeat ADC conversions
Buffer configuration
Description
Calibration lock
Offset calibration low-power TIA0 channel
Gain calibration for low-power TIA0 channel
Offset calibration low-power TIA1 channel
Gain calibration for low-power TIA1 channel
Offset calibration high-speed TIA channel
Gain calibration for high-speed TIA channel
Offset calibration voltage channel (PGA gain = 1)
Gain calibration voltage input channel (PGA gain = 1)
Offset calibration voltage input channel (PGA gain = 1.5)
Gain calibration voltage input channel (PGA gain = 1.5)
Offset calibration voltage input channel (PGA gain = 2)
Gain calibration voltage input channel (PGA gain = 2)
Offset calibration voltage input channel (PGA gain = 4)
Gain calibration voltage input channel (PGA gain = 4)
Offset calibration voltage input channel (PGA gain = 9)
Gain calibration voltage input channel (PGA gain = 9)
Offset calibration temperature sensor Channel 0
Gain calibration temperature sensor Channel 0
Description
Minimum value check
Minimum slow moving value
Maximum value check
Maximum slow moving
Delta check
Description
Statistics module configuration
Mean output
ADuCM356
Reset Access
0x00000000 R/W
0x00000301 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000090 R/W
0x00000000 R/W
0x00000037 R/W
0x00000160 R/W
0x005F3D00 R/W
Reset Access
0x00000000 R/W
0x00000000 R/W
0x00004000 R/W
0x00000000 R/W
0x00004000 R/W
0x00000000 R/W
0x00004000 R/W
0x00000000 R/W
0x00004000 R/W
0x00000000 R/W
0x00004000 R/W
0x00000000 R/W
0x00004000 R/W
0x00000000 R/W
0x00004000 R/W
0x00000000 R/W
0x00004000 R/W
0x00000000 R/W
0x00004000 R/W
Reset Access
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
Reset Access
0x00000000 R/W
0x00000000 R
