Reference Manual
REGISTER DETAILS: DIGITAL DIE WAKE-UP TIMER
Table 388. Bit Descriptions for CR1 (Continued)
Bits Bit Name
4 CNTMOD60ROLLINTEN
3 CNTROLLINTEN
2 Reserved
1 PSINTEN
0 CNTINTEN

STATUS 2 REGISTER

Address: 0x4000142C, Reset: 0xC000, Name: SR2
SR2 is a status register that further complements the status information provided by SR0 and SR1.
SR2 contains sticky interrupt sources optionally enabled via the CR1 register. These interrupt sources alert the CPU when the WUT count has
changed, when the prescaled gated clock that controls the advancement of the WUT count has activated, when a trim boundary has occurred,
when the 32-bit WUT count has rolled over, and when the modulo 60 version of the WUT count has rolled over.
All interrupt sources in SR2 are sticky, active high level signals. Each one can individually be cleared by writing a value of 0b1 to its bit position
in SR2.
Table 389. Bit Descriptions for SR2
Bits Bit Name
15 WSYNCALM2MIR
analog.com
Settings Description
MMRs. In contrast, RTC1 can prescale the clock by any power of two in the interval
Bits[15:0] to use as its time base.
0000 Prescale the WUT base clock by 2
0001 Prescale the WUT base clock by 2
0010 Prescale the WUT base clock by 2
0011 Prescale the WUT base clock by 2
0100 Prescale the WUT base clock by 2
0101 Prescale the WUT base clock by 2
0110 Prescale the WUT base clock by 2
0111 Prescale the WUT base clock by 2
1000 Prescale the WUT base clock by 2
1001 Prescale the WUT base clock by 2
1010 Prescale the WUT base clock by 2
1011 Prescale the WUT base clock by 2
1100 Prescale the WUT base clock by 2
1101 Prescale the WUT base clock by 2
1110 Prescale the WUT base clock by 2
1111 Prescale the WUT base clock by 2
Enable for the WUT Modulo 60 Count Roll Over Interrupt Source, CNTMOD60ROLLINT
in SR2.
0 Disable CNTMOD60ROLLINT interrupt.
1 Enable CNTMOD60ROLLINT interrupt.
Enable CNTROLLINT in SR2 for the WUT Count Roll Over Interrupt Source.
0 Disable CNTROLLINT as an indicator of the WUT peripheral interrupt.
1 Enable CNTROLLINT as an indicator of the WUT peripheral interrupt.
Reserved.
Enable for the Prescaled Modulo 1 Interrupt Source PSINT in SR2.
0 Disable PSINT in SR2 as an indicator of the WUT peripheral interrupt.
1 Enable PSINT in SR2 as an indicator of the WUT peripheral interrupt.
Enable for the WUT Count Interrupt Source, CNTINT in SR2.
0 Disable CNTINT in SR2 as an indicator of the WUT peripheral interrupt.
1 Enable CNTINT in SR2 as an indicator of the WUT peripheral interrupt.
Settings Description
Synchronization Status of Posted Writes to ALM2. This bit indicates if the effects of a posted
write to ALM2 are visible to the CPU.
0 Results of a posted write to CR1 are not yet visible to the CPU.
0
= 1.
1
= 2.
2
= 4.
3
= 8.
4
= 16.
5
= 32.
6
= 64.
7
= 128.
8
= 256.
9
= 512.
10
= 1024.
11
= 2048.
12
= 4096.
13
= 8192.
14
= 16384.
15
= 32768.
ADuCM356
Reset Access
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
Reset Access
0x1 R
Rev. A | 296 of 312
