One Technology Way • P.O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel: 781.329.4700 • Fax: 781.461.3113 • www.analog.com
Evaluating the
FEATURES
Self contained board, including
noise quadband VCO,
options, and
LT3042
connectivity to allow use of Arduino Uno or Linduino
microcontroller
Externally powered by a single 6 V supply
EVALUATION KIT CONTENTS
EV1HMC8362LP6G or EV1HMC8364LP6G evaluation board
EQUIPMENT NEEDED
Power supply (6 V)
Power supply (low noise, variable 0 V to 13.5 V)
50 Ω terminations
Signal source analyzer
ONLINE RESOURCES
HMC8362
data sheet
HMC8364
data sheet
Linduino DC2026C Demo Manual
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
Arrow.com.
Downloaded from
EV1HMC8362LP6G/EV1HMC8364LP6G
HMC8362/HMC8364
HMC8362
or
HMC8364
ADG1604
4:1 multiplexer, filtering
voltage regulator and header
EV1HMC8362LP6G/EV1HMC8364LP6G EVALUATION BOARD PHOTOGRAPH
Low Noise Quadband Voltage Controlled
Oscillators (VCOs)
GENERAL DESCRIPTION
The EV1HMC8362LP6G and EV1HMC8364LP6G allow the
low
evaluation of the performance of the HMC8362 and HMC8364
low noise quadband voltage controlled oscillators (VCOs). A
photograph of the evaluation board is shown in Figure 1. The
evaluation board contains the
LT3042
ultralow noise voltage regulator, a jumper, an
4:1 multiplexer, and subminiature Version A (SMA) and
2.92 mm K connectors.
Consult the
with this user guide when working with the evaluation boards.
Figure 1.
Rev. 0 | Page 1 of 11
HMC8362
or
HMC8362
and
HMC8364
data sheets in conjunction
User Guide
UG-1787
HMC8364
VCO, an
ADG1604
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Analog Devices EV1HMC8362LP6G
Summary of Contents for Analog Devices EV1HMC8362LP6G
-
Page 1: Features
One Technology Way • P.O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel: 781.329.4700 • Fax: 781.461.3113 • www.analog.com Evaluating the HMC8362/HMC8364 Low Noise Quadband Voltage Controlled Oscillators (VCOs) FEATURES GENERAL DESCRIPTION The EV1HMC8362LP6G and EV1HMC8364LP6G allow the Self contained board, including HMC8362 HMC8364 evaluation of the performance of the HMC8362 and HMC8364 noise quadband VCO, ADG1604... -
Page 2: Table Of Contents
Loop Filter ..................5 Online Resources ................1 Default Configuration ..............5 General Description ................. 1 Evaluation Board Software ...............6 EV1HMC8362LP6G/EV1HMC8364LP6G Evaluation Board Software ..................6 Photograph ..................1 Evaluation and Test ................7 Revision History ................2 Evaluation Board Schematic and Artwork ........8 Getting Started .................. -
Page 3: Getting Started
Connect the low noise, variable power supply to the SMA connector on the tuning port (J2) using a double shielded To configure the EV1HMC8362LP6G or EV1HMC8364LP6G for BNC cable and a BNC to SMA adapter. Torque this the first time, perform the following steps: connection to 8 in/lb using an SMA torque wrench. -
Page 4: Evaluation Board Hardware
114 mA (R6 = 1100 Ω) for the buffer amplifier was designed to handle the power supplied by EV1HMC8362LP6G and 156 mA (R6 = 806 Ω) for the only one VCO at a time. To prevent long-term damage that can EV1HMC8364LP6G. -
Page 5: Loop Filter
(VTUNE) when the the last pole of the loop filter, this user guide refers to the last EV1HMC8362LP6G and EV1HMC8364LP6G are used with an pole as that which can be accessed by the user. optional PLL evaluation board. J2 can also be used to manually... -
Page 6: Evaluation Board Software
Linduino, Arduino Uno, SDP-K1, Connector P3 (Pin 3 to Pin 15), respectively, as shown in or similar microcontroller board, which may be beneficial for Figure 3. Figure 3. SDP-K1 Board Mounted to the EV1HMC8362LP6G Rev. 0 | Page 6 of 11 Arrow.com. Arrow.com. -
Page 7: Evaluation And Test
SWEEP 4.600ms (1001pts) results in the output power decreasing by approximately Figure 5. EV1HMC8362LP6G, VCO Band 1, VTUNE = 8.45 V, 13.5 GHz, Buffer Amplifier Disabled (J3 Output Muted), Includes Insertion Loss of RF Cable 28 dBm. Refer to Figure 5. -
Page 8: Evaluation Board Schematic And Artwork
User Guide EVALUATION BOARD SCHEMATIC AND ARTWORK EV1HMC8362LP6G SCHEMATIC Figure 7 shows the schematic for the EV1HMC8362LP6G. For the EV1HMC8364LP6G variant, two component values that must be changed are highlighted within this schematic. Figure 7. EV1HMC8362LP6G Schematic Rev. 0 | Page 8 of 11 Arrow.com. -
Page 9: Silkscreen Layers
EV1HMC8362LP6G/EV1HMC8364LP6G User Guide UG-1787 SILKSCREEN LAYERS Figure 8. EV1HMC8362LP6G and EV1HMC8364LP6G Silk Screen and Metal 1 Figure 10. EV1HMC8362LP6G and EV1HMC8364LP6G Metal 3 (RF and DC) (Top Side) Figure 11. EV1HMC8362LP6G and EV1HMC8364LP6G Metal 4 (Backside) Figure 9. EV1HMC8362LP6G and EV1HMC8364LP6G Metal 2 (Ground) Rev. -
Page 10: Ordering Information
UG-1787 EV1HMC8362LP6G/EV1HMC8364LP6G User Guide ORDERING INFORMATION BILL OF MATERIALS Table 1. Reference Designator Description Value Manufacturer Part Number C1, C27, C28, C32, C29, Ceramic capacitor, X7R, automotive grade 0.1 µF Murata GCM155R71C104KA55D C5, C6, C7, C10 Ceramic capacitor, general-purpose 1000 pF... - Page 11 Legal Terms and Conditions By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the “Evaluation Board”), you are agreeing to be bound by the terms and conditions set forth below (“Agreement”) unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the Evaluation Board until you have read and agreed to the Agreement.
