REGISTER DETAILS: CLOCK ARCHITECTURE
Table 16. Bit Descriptions for CLKEN0 (Continued)
Bits Bit Name
1 SLPWUTDIS
0 WDTDIS

KEY PROTECTION FOR OSCCON REGISTER

Address: 0x400C0A0C, Reset: 0x0000, Name: OSCKEY
Table 17. Bit Descriptions for OSCKEY
Bits Bit Name Settings
[15:0] OSCKEY 0xCB14 Oscillator Control Key Register. The OSCCON register is key-protected. Write 0xCB14 to OSCKEY before

OSCILLATOR CONTROL REGISTER

Address: 0x400C0A10, Reset: 0x0303, Name: OSCCON
The OSCCON register is key protected. To unlock this protection, write 0xCB14 to the OSCKEY register before writing to the OSCCON register.
A write to any other register before writing to the OSCCON register returns the protection to the lock state.
Table 18. Bit Descriptions for OSCCON
Bits Bit Name Settings
[15:11] Reserved
10 HFXTALOK
9 HFOSCOK
8 LFOSCOK
[7:3] Reserved
2 HFXTALEN
1 HFOSCEN
0 LFOSCEN
