Analog Devices ADuCM356 Reference Manual page 163

Reference Manual
DMA CONTROLLER
Table 193. CHNL_CFG Control Data Configuration (Continued)
Source
Bit(s) Name Data Width
Half word
Word
[25:24] SRC_SIZE
[23:18] Reserved
[17:14] R_POWER
[13:4] N_MINUS_1
3 Reserved
[2:0] CYCLE_CTRL
analog.com
Setting Description
01 Source address increment is half word.
10 Source address increment is word.
11 No increment. Address remains set to the value contained in the SRC_END_PTR memory location.
00 Reserved.
01 Source address increment is half word.
10 Source address increment is word.
11 No increment. Address remains set to the value contained in the SRC_END_PTR memory location.
00 Reserved.
01 Reserved.
10 Source address increment is word.
11 No increment. Address remains set to the value contained in the SRC_END_PTR memory location.
Size of the Source Data.
00 Byte.
01 Half word.
10 Word.
11 Reserved.
Undefined. Write as 0.
DMA Transfers Before Rearbitration. Set these bits to control the number of DMA transfers can occur
before the controller rearbitrates. These bits must be set to 0000 for all DMA transfers involving peripherals.
Operation of the DMA is indeterminate if a value other than 0000 is programmed in this location for DMA
transfers involving peripherals.
0000 1
0001 2
0010 4
0011 8
0100 16
0101 32
0110 64
0111 128
1000 256
1001 512
1010 to 1024
1111
Number of Configured Transfers Minus 1 for that Channel. The 10-bit value indicates the number of DMA
transfers (not the total number of bytes) minus one.
0x000 1 DMA transfer.
0x001 2 DMA transfers.
0x002 3 DMA transfers.
...
0x3FF 1024 DMA transfers.
Undefined. Write as 0.
Transfer Types of DMA Cycle.
000 Stop (invalid).
001 Basic.
010 Autorequest.
011 Ping pong.
ADuCM356
Rev. A | 163 of 312
