REGISTER SUMMARY: UART

Table 320. UART Register Summary
Address Name
0x40005000 COMTX
0x40005000 COMRX
0x40005004 COMIEN
0x40005008 COMIIR
0x4000500C COMLCR
0x40005010 COMMCR
0x40005014 COMLSR
0x40005018 COMMSR
0x4000501C COMSCR
0x40005020 COMFCR
0x40005024 COMFBR
0x40005028 COMDIV
0x4000502C COMLCR2
0x40005030 COMCTL
0x40005034 COMRFC
0x40005038 COMTFC
0x4000503C COMRSC
0x40005040 COMACR
0x40005044 COMASRL
0x40005048 COMASRH
analog.com
Description
Transmit holding
Receive buffer
Interrupt enabler
Interrupt identification
Line control
Modem control
Line status
Modem status
Scratch buffer
FIFO control
Fractional baud rate
Baud rate divider
Second line control
UART control
Receive FIFO count
Transmit FIFO count
RS485 half-duplex control
Autobaud control
Autobaud status (low)
Autobaud status (high)
ADuCM356
Reset Access
0x0000 W
0x0000 R
0x0000 R/W
0x0001 RC
0x0000 R/W
0x0000 R/W
0x0060 RC
0x0000 RC
0x0000 R/W
0x0000 R/W
0x0000 R/W
0x0000 R/W
0x0002 R/W
0x0100 R/W
0x0000 R
0x0000 R
0x0000 R/W
0x0000 R/W
0x0000 R
0x0000 R
