Interrupt Registers - Analog Devices ADuCM356 Reference Manual

Reference Manual
AFE INTERRUPTS

INTERRUPT REGISTERS

Table 174. Interrupt Registers Summary
Address Name
0x400C3000 INTCPOL
0x400C3004 INTCCLR
0x400C3008 INTCSEL0
0x400C300C INTCSEL1
0x400C3010 INTCFLAG0
0x400C3014 INTCFLAG1
0x400C209C AFEGENINTSTA
Interrupt Polarity Register
Address: 0x400C3000, Reset: 0x00000000, Name: INTCPOL
Table 175. Bit Descriptions for INTCPOL Register
Bits Bit Name
[31:1] Reserved
0 INTPOL
Interrupt Clear Register
Address: 0x400C3004, Reset: 0x00000000, Name: INTCCLR
Table 176. Bit Descriptions for INTCCLR Register
Bits Bit Name Description
31 INTCLR31 Attempt to Break Interrupt (IRQ). Write 1 to clear.
30 Reserved Reserved.
29 INTCLR29 Outlier IRQ. Write 1 to clear.
28 Reserved Reserved.
27 INTCLR27 Data FIFO Underflow IRQ. Write 1 to clear.
26 INTCLR26 Data FIFO Overflow IRQ. Write 1 to clear.
25 INTCLR25 Data FIFO Threshold IRQ. Write 1 to clear.
24 INTCLR24 Data FIFO Empty IRQ. Write 1 to clear.
23 INTCLR23 Data FIFO Full IRQ. Write 1 to clear.
22 Reserved Reserved.
17 INTCLR17 Sequencer Timeout Error IRQ. Write 1 to clear.
16 INTCLR16 Sequencer Timeout Finished IRQ. Write 1 to clear.
15 INTCLR15 End of Sequence IRQ. Write 1 to clear.
14 Reserved Reserved.
13 INTCLR13 Boot Load Done IRQ. Write 1 to clear.
12 INTCLR12 Custom Interrupt 3. Write 1 to clear.
11 INTCLR11 Custom Interrupt 2. Write 1 to clear.
10 INTCLR10 Custom Interrupt 1. Write 1 to clear.
9 INTCLR9 Custom Interrupt 0. Write 1 to clear.
8 Reserved Reserved.
7 INTCLR7 Mean IRQ. Write 1 to clear.
analog.com
Description
Interrupt polarity register
Interrupt clear register
Interrupt controller select register
Interrupt controller select register
Interrupt controller flag register
Interrupt controller flag register
Analog generation interrupt register
Settings Description
Reserved.
Interrupt Polarity.
0 Output negative edge interrupt.
1 Output positive edge interrupt.
ADuCM356
Reset
0x00000000
0x00000000
0x00002000
0x00002000
0x00000000
0x00000000
0x00000010
Reset
0x0
0x0
Reset Access
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
Not applicable Not applicable
Not applicable Not applicable
Not applicable Not applicable
Not applicable Not applicable
0x0 W
0x0 W
Rev. A | 137 of 312
Access
R/W
W
R/W
R/W
R
R
R/W1C
Access
R
R/W
