REGISTER DETAILS: POWER MANAGEMENT UNIT
Table 30. Bit Descriptions for SRAM_INITSTAT (Continued)
Bits Bit Name
1 BNK1
0 BNK0

POWER MODES REGISTER

Address: 0x400C0A00, Reset: 0x0001, Name: PWRMOD
Table 31. Bit Descriptions for PWRMOD
Bits Bit Name Settings
[15:4] Reserved
3 SEQSLPEN
2 TMRSLPEN
[1:0] PWRMOD

KEY PROTECTION FOR PWRMOD REGISTER

Address: 0x400C0A04, Reset: 0x0000, Name: PWRKEY
Table 32. Bit Descriptions for PWRKEY
Bits Bit Name Settings
[15:0] PWRKEY
analog.com
Settings Description
0 Not initialized.
1 Initialization completed.
Initialization Status of SRAM Bank 1.
0 Not initialized.
1 Initialization completed.
Initialization Status of SRAM Bank 0.
0 Not initialized.
1 Initialization completed.
Description
Reserved.
Autosleep Function by Sequencer Command.
0 Disables the sequencer autosleep function.
1 Enables the sequencer autosleep function.
Autosleep Function by Sleep and Wake-Up Timer.
0 Disables the sleep and wake-up timer autosleep function.
1 Enables the sleep and wake-up timer autosleep function.
Power Mode Control Bits. When read, these bits contain the last power mode value entered by user
code.
00, 11 Reserved. Do not enter this mode.
01 Active Mode. Normal working mode. All digital circuits powered up. User can optionally power down
blocks by disabling their input clock.
10 Hibernate Mode. Digital core powered down, most analog die blocks are powered down. Low-power
DACs or references can remain active to bias an external sensor. The high-speed clock is powered
down. Only the low-speed clock is powered up.
Description
PWRMOD Key Register. The PWRMOD register is key protected. Two writes to the key are necessary to
change the value in the PWRMOD register: first 0x4859, then 0xF27B. A write to any other register before
writing to PWRMOD returns the protection to the lock state.
ADuCM356
Reset Access
0x0 R
0x1 R
Reset
0x0
0x0
0x0
0x1
Reset
0x0
Rev. A | 32 of 312
Access
R
R/W
R/W
R/W
Access
R/W
