REGISTER SUMMARY: LOW-POWER TIA/POTENTIOSTAT AND DAC CIRCUITS

Table 107. Low-Power Potentiostat and TIA Control Register Summary
Address Name
0x400C20EC LPTIACON0
0x400C20E4 LPTIASW0
0x400C20E8 LPTIACON1
0x400C20E0 LPTIASW1
Table 108. Low-Power DAC Control Register Summary
Address Name
0x400C2120 LPDACDAT0
0x400C2124 LPDACSW0
0x400C2128 LPDACCON0
0x400C212C LPDACDAT1
0x400C2130 LPDACSW1
0x400C2134 LPDACCON1
0x400C2050 LPREFBUFCON
analog.com
Description
Low-power TIA control bits Channel 0
Low-power TIA switch configuration for Channel 0
Low-power TIA control bits Channel 1
Low-power TIA switch configuration for Channel 1
Description
Low-power DAC0 data out
Low-power DAC0 switch control
Low-power DAC0 control
Low-power DAC1 data out
Low-power DAC1 switch control
Low-power DAC1 control
Low-power reference control
ADuCM356
Reset Access
0x00000003 R/W
0x00000000 R/W
0x00000003 R/W
0x00000000 R/W
Reset Access
0x00000000 R/W
0x00000000 R/W
0x00000002 R/W
0x00000000 R/W
0x00000000 R/W
0x00000002 R/W
0x00000000 R/W
