REGISTER SUMMARY: GENERAL-PURPOSE TIMERS

Table 342. Timer Register Summary
Address Name
0x40000000 GPT0_LOAD
0x40000004 GPT0_CURCNT
0x40000008 GPT0_CTL
0x4000000C GPT0_CLRINT
0x40000010 GPT0_CAPTURE
0x40000014 GPT0_ALOAD
0x40000018 GPT0_ACURCNT
0x4000001C GPT0_STAT
0x40000400 GPT1_LOAD
0x40000404 GPT1_CURCNT
0x40000408 GPT1_CTL
0x4000040C GPT1_CLRINT
0x40000410 GPT1_CAPTURE
0x40000414 GPT1_ALOAD
0x40000418 GPT1_ACURCNT
0x4000041C GPT1_STAT
0x40000800 GPT2_LOAD
0x40000804 GPT2_CURCNT
0x40000808 GPT2_CTL
0x4000080C GPT2_CLRINT
0x40000810 GPT2_CAPTURE
0x40000814 GPT2_ALOAD
0x40000818 GPT2_ACURCNT
0x4000081C GPT2_STAT
analog.com
Description
16-bit synchronous load value
16-bit timer synchronous value
Control
Clear interrupt
Capture
16-bit asynchronous load value
16-bit timer asynchronous value
Status
16-bit synchronous load value
16-bit timer synchronous value
Control
Clear interrupt
Capture
16-bit asynchronous load value
16-bit timer asynchronous value
Status
16-bit synchronous load value
16-bit timer synchronous value
Control
Clear interrupt
Capture
16-bit asynchronous load value
16-bit timer asynchronous value
Status
ADuCM356
Reset Access
0x0000 R/W
0x0000 R
0x000A R/W
0x0000 W
0x0000 R
0x0000 R/W
0x0000 R
0x0000 R
0x0000 R/W
0x0000 R
0x000A R/W
0x0000 W
0x0000 R
0x0000 R/W
0x0000 R
0x0000 R
0x0000 R/W
0x0000 R
0x000A R/W
0x0000 W
0x0000 R
0x0000 R/W
0x0000 R
0x0000 R
