Reference Manual
REGISTER DETAILS: ADC CIRCUIT
Table 76. Bit Descriptions for ADCBUFCON (Continued)
Bits Bit Name
2 CHOPDIS
1 CHOPDIS
0

CALIBRATION LOCK REGISTER

Address: 0x400C2230, Reset: 0x00000000, Name: CALDATLOCK
Table 77. Bit Descriptions for CALDATLOCK
Bits Bit Name Settings
[31:0] KEY

OFFSET CALIBRATION LOW-POWER TIA0 CHANNEL REGISTER

Address: 0x400C2288, Reset: 0x00000000, Name: ADCOFFSETLPTIA0
Table 78. Bit Descriptions for ADCOFFSETLPTIA0
Bits Bit Name Settings
[31:15] Reserved
[14:0] VALUE

GAIN CALIBRATION FOR LOW-POWER TIA0 CHANNEL REGISTER

Address: 0x400C228C, Reset: 0x00004000, Name: ADCGNLPTIA0
Table 79. Bit Descriptions for ADCGNLPTIA0
Bits Bit Name Settings
[31:15] Reserved
[14:0] VALUE
analog.com
Settings Description
1 Disable chop.
Configure ADC Buffer Chop.
0 Enable chop.
1 Disable chop.
Configure PGA Chop.
0 Enable chop.
1 Disable chop.
Configure Front-End Buffer Chop.
0 Enable chop.
1 Disable chop.
Description
Password for Calibration Data Registers. Prevents overwriting of data after the
calibration phase.
0xDE87A5AF Calibration data registers read/write.
Description
Reserved.
Offset Calibration for Low-Power TIA0. Represented as a twos complement number. The calibration
resolution is 0.25 LSBs of the ADCDAT LSB size.
0x3FFF 4095.75 (maximum positive offset calibration value).
0x0001 0.25 (minimum positive offset calibration value).
0x0000 0 (no offset adjustment).
0x7FFF −0.25 (minimum negative offset calibration value).
0x4000 −4096.0 (maximum negative offset calibration value).
Description
Reserved.
Gain Error Calibration for Low-Power TIA0. ADC offset correction in TIA measurement mode,
represented as a twos complement number.
0x7FFF 2 (maximum positive gain adjustment).
0x4001 1.000061 (minimum positive gain adjustment).
0x4000 1.0. ADC result multiplied by 1. No gain adjustment. Default value.
0x3FFF 0.999939 (minimum negative gain adjustment).
0x2000 0.5. ADC result multiplied by 0.5.
0x0001 0.000061 (maximum negative gain adjustment).
ADuCM356
Reset Access
0x0 R/W
0x0 R/W
Reset Access
0x0 R/W
Reset Access
0x0 R
0x0 R/W
Reset Access
0x0 R
0x4000 R/W
Rev. A | 71 of 312
