Transfer Byte Count Registers; Dma Enable Registers - Analog Devices ADuCM356 Reference Manual

Reference Manual
REGISTER DETAILS: SPI0/SPI1
Table 311. Bit Descriptions for SPI0_IEN, SPI1_IEN (Continued)
Bits Bit Name Settings
001 Transmit interrupt occurs when 2 bytes have been transferred. Receive interrupt occurs when 2 or more
010 Transmit interrupt occurs when 3 bytes have been transferred. Receive interrupt occurs when 3 or more
011 Transmit interrupt occurs when 4 bytes have been transferred. Receive interrupt occurs when 4 or more
100 Transmit interrupt occurs when 5 bytes have been transferred. Receive interrupt occurs when 5 or more
101 Transmit interrupt occurs when 6 bytes have been transferred. Receive interrupt occurs when 6 or more
110 Transmit interrupt occurs when 7 bytes have been transferred. Receive interrupt occurs when 7 or more

TRANSFER BYTE COUNT REGISTERS

Address: 0x40004018, Reset: 0x0000, Name: SPI0_CNT
Address: 0x40024018, Reset: 0x0000, Name: SPI1_CNT
This register is only used in initiator mode.
Table 312. Bit Descriptions for SPI0_CNT, SPI1_CNT
Bits Bit Name Settings
15 FRAMECONT
14 Reserved
[13:0] VALUE

DMA ENABLE REGISTERS

Address: 0x4000401C, Reset: 0x0000, Name: SPI0_DMA
Address: 0x4002401C, Reset: 0x0000, Name: SPI1_DMA
Table 313. Bit Descriptions for SPI0_DMA, SPI1_DMA
Bits Bit Name Settings
[15:3] Reserved
2 RXEN
1 TXEN
analog.com
Description
bytes have been received into the FIFO.
bytes have been received into the FIFO.
bytes have been received into the FIFO.
bytes have been received into the FIFO.
bytes have been received into the FIFO.
bytes have been received into the FIFO.
111 Transmit interrupt occurs when 8 bytes have been transferred. Receive interrupt occurs when the FIFO is
full.
Description
Continue Frame. Use this bit in conjunction with the SPIx_CTL, Bit 11 and SPIx_CNT, Bits[13:0] fields.
This bit is used to control SPI data framing.
0 When writing to this bit, if this bit is cleared, the SPI initiator transfers only one frame of SPIx_CNT,
Bits[13:0]. When reading this bit, if the value bits > 0, stop SPI transfers after the specified number of
bytes.
1 When writing to this bit, the SPI initiator transfers data in frames of SPIx_CNT, Bits[13:0] bytes per
frame. If SPIx_CNT, Bits[13:0] = 0, this field has no effect because the SPI initiator continues with
transfers as long as the transmit or receive FIFO is ready. If SPIx_CTL, Bit 11 = 0, this field has no
effect because all SPI frames are a single byte wide, irrespective of other control fields. When reading
this bit, continue SPI transfers as long as the transmit or receive FIFO is ready.
Reserved.
Transfer Byte Count. This field specifies the number of bytes to be transferred. It is used in both
receive and transmit transfer types. This value ensures that an initiator mode transfer terminates at the
proper time and that 16-bit SPIx_DMA transfers are byte padded or discarded as required to match
odd transfer counts. Reset by clearing SPIx_CTL, Bit 0 to 0.
Description
Reserved.
Enable Receive DMA Request.
0 Disable receive DMA interrupt.
1 Enable receive DMA interrupt.
Enable Transmit DMA Request.
ADuCM356
Reset Access
Reset Access
0x0 R/W
0x0 R
0x0 R/W
Reset Access
0x0 R
0x0 R/W
0x0 R/W
Rev. A | 248 of 312
