Analog Devices ADuCM356 Reference Manual page 134

Reference Manual
SEQUENCER
Command Data Control Register
Address: 0x400C21D8, Reset: 0x00000410, Name: CMDDATACON
Table 167. Bit Descriptions for CMDDATACON Register
Bits Bit Name
[31:12] Reserved
[11:9] DATAMEMMDE
[8:6] DATA_MEM_SEL
[5:3] CMDMEMMDE
[2:0] CMD_MEM_SEL
Data FIFO Threshold Register
Address: 0x400C21E0, Reset: 0x00000000, Name: DATAFIFOTHRES
Table 168. Bit Descriptions for DATAFIFOTHRES Register
Bits Bit Name
[31:27] Reserved
[26:16] HIGHTHRES
[15:0] Reserved
Sequence 3 Information Register
Address: 0x400C21E4, Reset: 0x00000000, Name: SEQ3INFO
Table 169. Bit Descriptions for SEQ3INFO Register
Bits Bit Name
[31:27] Reserved
[26:16] INSTNUM
[15:11] Reserved
[10:0] STARTADDR
Sequence 1 Information Register
Address: 0x400C21E8, Reset: 0x00000000, Name: SEQ1INFO
analog.com
Settings Description
Reserved.
Data FIFO Mode Select.
10 FIFO mode.
11 Stream mode.
Data FIFO Size Select.
000 Reserved.
001 2 kB SRAM.
010 4 kB SRAM.
011 6 kB SRAM.
Command FIFO Mode.
01 Memory mode.
10 Reserved.
11 Reserved.
Command Memory Select.
0x0 Reserved.
0x1 2 kB SRAM.
0x2 4 kB SRAM.
0x3 6 kB SRAM.
Description
Reserved.
High Threshold.
Reserved.
Description
Reserved.
SEQ3 Instruction Number.
Reserved.
SEQ3 Start Address.
ADuCM356
Reset Access
0x0 R
0x2 R/W
0x0 R/W
0x2 R/W
0x0 R/W
Reset Access
0x0 R
0x0 R/W
0x0 R
Reset Access
0x0 R
0x0 R/W
0x0 R
0x0 R/W
Rev. A | 134 of 312
