Reference Manual
REGISTER DETAILS: DMA
STATUS REGISTER
Address: 0x40010000, Reset: 0x00180000, Name: STAT
Table 197. Bit Descriptions for STAT
Bits
Bit Name
Settings
[31:21]
Reserved
[20:16]
CHANM1
[15:1]
Reserved
0
MEN
CONFIGURATION REGISTER
Address: 0x40010004, Reset: 0x00000000, Name: CFG
Table 198. Bit Descriptions for CFG
Bits
Bit Name
[31:1]
Reserved
0
MEN
CHANNEL PRIMARY CONTROL DATA BASE POINTER REGISTER
Address: 0x40010008, Reset: 0x00000000, Name: PDBPTR
The PDBPTR register must be programmed to point to the channel primary control data base pointer in the system memory. The amount of
system memory that must be assigned to the DMA controller depends on the number of DMA channels used and whether the alternate channel
control data structure is used. This register cannot be read when the DMA controller is in the reset state.
Table 199. Bit Descriptions for PDBPTR
Bits
Bit Name
Settings
[31:0]
ADDR
CHANNEL ALTERNATE CONTROL DATA BASE POINTER REGISTER
Address: 0x4001000C, Reset: 0x00000200, Name: ADBPTR
The ADBPTR read only register returns the base address of the alternate channel control data structure. This register removes the necessity for
application software to calculate the base address of the alternate data structure. This register cannot be read when the DMA controller is in the
reset state.
Table 200. Bit Descriptions for ADBPTR
Bits
Bit Name
[31:0]
ADDR
CHANNEL SOFTWARE REQUEST REGISTER
Address: 0x40010014, Reset: 0x00000000, Name: SWREQ
The SWREQ register enables the generation of a software DMA request. Each bit of the register represents the corresponding channel number
in the DMA controller. M is the number of DMA channels.
analog.com
Description
Reserved.
Number of Available DMA Channels Minus 1. With 24 channels available, the register reads back 0x17.
Reserved.
Enable Status Of The Controller.
0 Controller is disabled.
1 Controller is enabled.
Settings
0 Disable controller.
1 Enable controller.
Description
Pointer to the Base Address of the Primary Data Structure. 5 + log
must be written as 0, where M is number of channels.
Settings
Description
Base Address of the Alternate Data Structure.
Description
Reserved.
Controller Enable.
M LSBs are reserved and
2
ADuCM356
Reset
0x000
0x18
0x000
0x0
Reset
Access
0x0000000
R
0x0
W
Reset
0x00000000
Reset
Access
0x200
R
Rev. A | 171 of 312
Access
R
R
R
R
Access
R/W
