REGISTER DETAILS: CLOCK ARCHITECTURE
Table 18. Bit Descriptions for OSCCON (Continued)
Bits Bit Name Settings

HIGH-POWER OSCILLATOR CONFIGURATION REGISTER

Address: 0x400C20BC, Reset: 0x00000024, Name: HPOSCCON
Table 19. Bit Descriptions for HPOSCCON
Bits Bit Name Settings
[31:3] Reserved
2 CLK32MHZEN
[1:0] Reserved

POWER MODE CONFIGURATION REGISTER

Address: 0x400C22F0, Reset: 0x00000000, Name: PMBW
This register configures the high and low-power system mode for the high-speed DAC and ADC circuits.
Table 20. Bit Descriptions for PMBW
Bits Bit Name Settings
[31:4] Reserved
[3:2] SYSBW
1 Reserved
0 SYSHP
analog.com
Description
1 The low frequency oscillator is enabled.
Description
Reserved.
16 MHz or 32 MHz Output Selector Signal. Select an output of 32 MHz or 16 MHz. The ADC can
run at 32 MHz, but the system clock cannot run at 32 MHz. Divide the system clock by 2 first before
switching the oscillator to 32 MHz. Refer to CLKCON0, Bits[5:0].
0 Select 32 MHz output.
1 Select 16 MHz output.
Reserved.
Description
Reserved.
Configure System Bandwidth. Configures the bandwidth of the high-speed DAC reconstruction filter
and the ADC antialias filter.
00 Reserved.
01 50 kHz, −3 dB bandwidth.
10 100 kHz, −3 dB bandwidth.
11 250 kHz, −3 dB bandwidth.
Reserved.
Set High-Speed DAC and ADC in High-Power Mode.
0 Low-power mode. Clear this bit for impedance measurements <80 kHz.
1 High-power mode. Set this bit for impedance measurements >80 kHz.
ADuCM356
Reset Access
Reset Access
0x0 R
0x1 R/W
0x0 R
Reset Access
0x0000000 R
0x0 R/W
0x0 R
0x0 R/W
Rev. A | 22 of 312
