Analog Devices ADuCM356 Reference Manual page 146

Reference Manual
SLEEP AND WAKE-UP TIMER
Table 182. Bit Descriptions for SEQORDER Register (Continued)
Bits Bit Name Settings
[3:2] SEQB
[1:0] SEQA
Sequence 0 to Sequence 3 Wake-Up Time Registers (LSB)
Address: 0x400C0808, Reset: 0xFFFF, Name: SEQ0WUPL
Address: 0x400C0818, Reset: 0xFFFF, Name: SEQ1WUPL
Address: 0x400C0828, Reset: 0xFFFF, Name: SEQ2WUPL
Address: 0x400C0838, Reset: 0xFFFF, Name: SEQ3WUPL
These registers set the sequence sleep time. The counter is 20 bits. These registers set the 16 LSBs. When this timer elapses, the device
wakes up.
Table 183. Bit Descriptions for SEQxWUPL Registers
Bits Bit Name
[15:0] WAKEUPTIME0[15:0]
Sequence 0 to Sequence 3 Wake-Up Time Registers (MSB)
Address: 0x400C080C, Reset: 0x000F, Name: SEQ0WUPH
Address: 0x400C081C, Reset: 0x000F, Name: SEQ1WUPH
Address: 0x400C082C, Reset: 0x000F, Name: SEQ2WUPH
Address: 0x400C083C, Reset: 0x000F, Name: SEQ3WUPH
These registers set the sequence sleep time. The counter is 20 bits. These registers set the 4 MSBs. When this timer elapses, the device
wakes up.
Table 184. Bit Descriptions for SEQxWUPH Registers
Bits Bit Name
[15:4] Reserved
[3:0] WAKEUPTIME0[19:16]
Sequence 0 to Sequence 3 Sleep Time Registers (LSB)
Address: 0x400C0810, Reset: 0xFFFF, Name: SEQ0SLEEPL
analog.com
Description
01 Fills in SEQ1.
10 Fills in SEQ2.
11 Fills in SEQ3.
Sequence B Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence B.
00 Fills in SEQ0.
01 Fills in SEQ1.
10 Fills in SEQ2.
11 Fills in SEQ3.
Sequence A Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence A.
00 Fills in SEQ0.
01 Fills in SEQ1.
10 Fills in SEQ2.
11 Fills in SEQ3.
Description
Sequence and Sleep Period. This register defines the length of time in which the device stays in sleep
mode. When this time elapses, the device wakes up.
Description
Reserved.
Sequence and Sleep Period. This register defines the length of time in which the device stays in sleep
mode. When this time elapses, the device wakes up.
ADuCM356
Reset Access
0x0 R/W
0x0 R/W
Reset Access
0xFFFF R/W
Reset Access
0x0 R
0xF R/W
Rev. A | 146 of 312
