Analog Devices ADuCM356 Reference Manual page 131

Reference Manual
SEQUENCER
Table 155. Bit Descriptions for SEQCON Register
Bits Bit Name
[31:16] Reserved
[15:8] SEQWRTMR
[7:5] Reserved
4 SEQHALT
[3:2] Reserved
1 SEQHALTFIFOEMPTY
0 SEQEN
FIFO Configuration Register
Address: 0x400C2008, Reset: 0x00001010, Name: FIFOCON
Table 156. Bit Descriptions for FIFOCON Register
Bits Bit Name
[31:16] RESERVED
[15:13] DATAFIFOSRCSEL
12 Reserved
11 DATAFIFOEN
[10:0] Reserved
Sequencer CRC Value Register
Address: 0x400C2060, Reset: 0x00000001, Name: SEQCRC
The SEQCRC register forms the checksum value calculated from all the commands executed by the sequencer.
Table 157. Bit Descriptions for SEQCRC Register
Bits Bit Name
[31:8] Reserved
analog.com
Settings Description
Reserved.
Sequencer Write Commands Timer. These bits act as a clock divider affecting only the
write commands, not the wait commands. This divider is useful to reduce the code size
when generating arbitrary waveforms. The clock source for the timer is ACLK.
Reserved.
Halt Sequence Debugging Feature. This bit provides a way to halt the AFE interface.
0 Normal execution.
1 Execution halted.
Reserved.
Halt Sequencer. This bit controls whether the sequencer stops when attempting to read
when the command FIFO is empty (in an underflow condition).
1 Sequencer stops if command FIFO is empty and sequencer attempts to read (in an
underflow condition).
0 Sequencer continues to attempt to read, even if the FIFO is empty.
Enable Sequencer. When this bit is set to 1, the sequencer reads from the command FIFO
and executes the commands.
0 Sequencer disabled (default).
1 Sequencer enabled.
Settings Description
Reserved.
Data FIFO Source Select.
000, 001, 110, or ADC data. The ADC data is the output of the sinc3 filter.
111
010 DFT data. The real part is 18 bits, and the imaginary part is 18 bits. The lowest two bits
are fractional because the ADC is 16 bits.
011 Sinc2 filter output, data is 16 bits.
100 Statistic variance output.
101 Mean result, mean is 16 bits of data.
Reserved.
Data FIFO Enable.
0 FIFO is reset, no data transfers can take place. This setting sets the read and write
pointers to the default values (FIFO empty). The status indicates that the FIFO is empty.
1 Normal operation, the FIFO is not reset.
Reserved.
Description
Reserved.
ADuCM356
Reset Access
0x0 R
0x0 R/W
0x0 R
0x0 R/W
0x0 R
0x1 R/W
0x0 R/W
Reset Access
0x0 R
0x0 R/W
0x1 R/W
0x0 R/W
0x0 R/W
Reset Access
0x0 R
Rev. A | 131 of 312
