Analog Devices ADuCM356 Reference Manual page 145

Reference Manual
SLEEP AND WAKE-UP TIMER
Table 181. Bit Descriptions for CON Register (Continued)
Bits Bit Name Settings
[5:4] RESERVED
[3:1] ENDSEQ
0 EN
Order Control Register
Address: 0x400C0804, Reset: 0x0000, Name: SEQORDER
The SEQORDER register controls the command sequence execution order.
Table 182. Bit Descriptions for SEQORDER Register
Bits Bit Name Settings
[15:14] SEQH
[13:12] SEQG
[11:10] SEQF
[9:8] SEQE
[7:6] SEQD
[5:4] SEQC
analog.com
Description
Reserved.
End Sequence. These bits select one of the SEQORDER bits to end the timing sequence.
000 The sleep and wake-up timer stops at Sequence A and then goes back to Sequence A.
001 The sleep and wake-up timer stops at Sequence B and then goes back to Sequence A.
010 The sleep and wake-up timer stops at Sequence C and then goes back to Sequence A.
011 The sleep and wake-up timer stops at Sequence D and then goes back to Sequence A.
100 The sleep and wake-up timer stops at Sequence E and then goes back to Sequence A.
101 The sleep and wake-up timer stops at Sequence F and then goes back to Sequence A.
110 The sleep and wake-up timer stops at Sequence G and then goes back to Sequence A.
111 The sleep and wake-up timer stops at Sequence H and then goes back to Sequence A.
Sleep and Wake-Up Timer Enable Bit.
0 Disables the sleep and wake-up timer.
1 Enables the sleep and wake-up timer.
Description
Sequence H Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence H.
00 Fills in SEQ0.
01 Fills in SEQ1.
10 Fills in SEQ2.
11 Fills in SEQ3.
Sequence G Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence G.
00 Fills in SEQ0.
01 Fills in SEQ1.
10 Fills in SEQ2.
11 Fills in SEQ3.
Sequence F Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence F.
00 Fills in SEQ0.
01 Fills in SEQ1.
10 Fills in SEQ2.
11 Fills in SEQ3.
Sequence E Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence E.
00 Fills in SEQ0.
01 Fills in SEQ1.
10 Fills in SEQ2.
11 Fills in SEQ3.
Sequence D Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence D.
00 Fills in SEQ0.
01 Fills in SEQ1.
10 Fills in SEQ2.
11 Fills in SEQ3.
Sequence C Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence C.
00 Fills in SEQ0.
ADuCM356
Reset Access
0x0 R
0x0 R/W
0x0 R/W
Reset Access
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
Rev. A | 145 of 312
