Table 30. Z8L180 DC Characteristics (Continued)
Symbol Item
ICC Power Dissipation*
(Normal Operation)
Power Dissipation*
(SYSTEM STOP
Mode)
Power Dissipation*
(IDLE Mode)
Power Dissipation*
(STANDBY Mode)
CP Pin Capacitance
Notes: * VIN min = V
V = 3.3V
CC
UM005004-0918
Condition
f = 20 MHz
f = 20 MHz
f = 20 MHz
External Oscillator,
Internal Clock Stops
VIN = 0V,
f = 1MHz
TA = 25°C
–1.0V. VIL max = 0.8V (All output terminals are a no load.)
CC
Minimum Typical Maximum Unit
20
2
3
4
– –
100 mA
10 mA
10 mA
μA
10
12 pF
