Z8018x
Family MPU User Manual
130
Bit
Position Bit/Field R/W
–
2
0
MOD2
UM005004-0918
Value
–
0 R/W
Description
ASCI Data Format Mode 2, 1, 0 — These bits program
the ASCI data format as follows.
MOD2
0: 7 bit data
1: 8 bit data
MOD1
0: No parity
1: Parity enabled
MOD0
0: 1 stop bit
1: 2 stop bits
The data formats available based on all combinations of
MOD2, MOD1 and MOD0 are described in Table 17.
