  • Page 7: Introduction

    The Z8 Encore! XP microcontroller products. The Z8 Encore! XP (Z8F04A08100KIT) enables users to become familiar with the hardware and software tools available with this product. This kit consists of the 4KB version of the Z8 Encore! Development board that supports and pre- sents the features of the Z8 Encore! XP 4K Series 8-pin package.
  • Page 8: Software (On Cd-Rom)

    Z8F04A08100KIT Development Kit User Manual Packaging Development Board Figure 1. Z8 Encore! XP Software (on CD-ROM) • ZDS II- Z8 Encore! • Sample code • Document browser • Acrobat Reader install program Introduction Power Supply ® 4K Series 8-Pin Development Kit Contents (Printed Quick Start Guide Not Shown) ®...
  • Page 9: Documentation

    Win98 Second Edition, Win2000 Service Pack 3, WinXP Profes- sional Service Pack 1 • PentiumII/233MHz processor or higher up to Pentium IV, 2.8 GHz • 96 MB RAM or more UM018702-0505 Z8F04A08100KIT Development Kit in the user's disk drive. User Manual <installa- Introduction...
  • Page 10: Designing With The Usb Smart Cable

    The Z8 Encore! XP 4K Series 8-Pin Development Kit requires use of the USB Smart Cable (supplied). The Z8 Encore! Serial Smart Cable and associated TIM will not work with the Z8F04A08100KIT kit. When designing your target board and application: •...
  • Page 11: Installation

    Installation Follow the directions in the Quick Start Guide (QS0043) for software installation and setup of the Z8 Encore! XP 4K Series 8-Pin Development kit. UM018702-0505 Z8F04A08100KIT Development Kit User Manual Installation...
  • Page 12 Z8F04A08100KIT Development Kit User Manual Installation UM018702-0505...
  • Page 13: Development Board

    Resonator not installed on production units. Figure 2. Z8 Encore! XP UM018702-0505 Z8F04A08100KIT Development Kit ® 4K Series 8-Pin Development board is a develop- ® 4K Series 8-Pin Development Board User Manual Pin 1 Development Board...
  • Page 14: Features

    Z8F04A08100KIT Development Kit User Manual Features • Z8 Encore! • 3 LEDs • RS-232 interface • IrDA transceiver • Two pushbuttons, RESET and TEST • 5 VDC power connector • On-Chip Debugger interface • Prototyping area • External interface connectors JP1 and JP2 •...
  • Page 15: Uart With Irda Endec

    • 1KB register RAM • 5-channel, 10-bit analog-to-digital converter (ADC) • Full-duplex UART • Infrared Data Association (IrDA)-compliant infrared encoder/decoder • Two 16-bit timers with capture, compare, and PWM capability • Watch-Dog Timer (WDT) with internal RC oscillator • Six I/O pins •...
  • Page 16: Jumpers And Settings

    Z8F04A08100KIT Development Kit User Manual Jumpers and Settings Table 1 provides information on jumper functions. Table 1. Z8F04A08100KIT Jumper Functions Jumper State Development Board Description Enables RS-232 interface Disables RS-232 interface Enables IrDA interface Disables IrDA interface Connects U5 pin PA0 to Green...
  • Page 17: Demo Mode Jumper Settings

    Table 1. Z8F04A08100KIT Jumper Functions Jumper State Note: * These jumpers must not be OUT at the same time The board has two modes of operation: DEMO and USER. Use DEMO mode to run the sample program included with the kit. Run the board in USER mode: •...
  • Page 18: User Debug Mode Jumper Settings

    Z8F04A08100KIT Development Kit User Manual J3 1-2 J4 OUT J5 1-2 J6 1-2 J7 OUT J8 1-2 J9 1-2 J10 1-2 J11 OUT USER DEBUG Mode Jumper Settings When running the board in USER DEBUG mode, the following jumpers MUST be set:...
  • Page 19: Use Of Ceramic Resonator Y1

    Use of Ceramic Resonator Y1 When using ceramic resonator Y1, pins PA0, PA1, and DBG are unavail- able to the user. For more information, refer to the Z8 Encore! XP™ 4K Series Product Specification, PS0228. UM018702-0505 Z8F04A08100KIT Development Kit User Manual Development Board...
  • Page 20 Z8F04A08100KIT Development Kit User Manual Development Board UM018702-0505...
  • Page 21: Schematic

    Schematic This section includes schematics for the Z8 Encore! XP 4K Series 8-Pin Development Board. UM018702-0505 Z8F04A08100KIT Development Kit User Manual Schematic...
  • Page 22 Z8F04A08100KIT Development Kit User Manual UM018702-0505 Schematic...
  • Page 23 PWR JACK 0.1uF SW KEY-SPDT VOUT SPX2815AU-3.3 0.1uF VCC_33V 74LVC04/SO VCC_33V 74LVC04/SO VCC_33V 74LVC04/SO VCC_33V 74LVC04/SO Schematic, Z8 Encore! XP™ 4K Series 8-Pin MCU Development Board, Page 1 of 2 UM018702-0505 + C3 10/6 HEADER 2 VCC_33V VCC_33V + C7 PA3_CTS0 PA3_CTS0 10/6...
  • Page 24 VCC_33V VCC_33V VCC_33V VCC_33V VCC_33V VCC_33V VCC_33V PA3_CTS0 TEST PA0_JP PA1_JP 8 pin footprint VCC_33V PA5_JP PA4_JP PA3_CTS0 PA2_JP PA3_JP Z8F04xA_8pin PA4_RXD0 220K PA5_TXD0 20 MHz NOTE 2 TABLE 1 Clock Mode Internal Note 2 Note 2 none none none none Ceramic Res none...
