ASCI Control Register A0, 1 (CNTLA0, 1)
Each ASCI channel Control Register A configures the major operating modes
such as receiver/transmitter enable and disable, data format, and multiprocessor
communication mode.
ASCI Status Register 1 (STAT1: 05H)
Bit 7
Bit/Field RDRF
R/W R
Reset 0
Note: R = Read W = Write X = Indeterminate ? = Not Applicable
Bit
Position Bit/Field R/W
7 RDRF
6 OVRN
5 PE
6 5
OVRN PE
R R
0 0
Value Description
R Receive Data Register Full — RDRF is set to 1 when an
incoming data byte is loaded into RDR. Note that if a
framing or parity error occurs, RDRF is still set and the
receive data (which generated the error) is still loaded
into RDR. RDRF is cleared to 0 by reading RDR, when
the DCD0 input is High, in IOSTOP mode, and during
RESET.
R Overrun Error — OVRN is set to 1 when RDR is full
and RSR becomes full. OVRN is cleared to 0 when the
EFR bit (Error Flag Reset) of CNTLA is written to 0,
when DCD0 is High, in IOSTOP mode, and during
RESET.
R Parity Error — PE is set to 1 when a parity error is
detected on an incoming data byte and ASCI parity
detection is enabled (the MOD1 bit of CNTLA is set to
1). PE is cleared to 0 when the EFR bit (Error Flag Reset)
of CNTLA is written to 0, when DCD0 is High, in
IOSTOP mode, and during RESET.
Family MPU User Manual
4 3
FE RIE CTS1E
R R/W R/W
0 0
Z8018x
2 1 0
TDRE TIE
R R/W
0 0 0
