Z8018x
Family MPU User Manual
138
ASCI1 Time Constant Low Register (I/O Address: 1CH) (Z8S180/L180-Class Processors
Only)
Bit
R/W R/W
Reset
Note: R = Read W = Write X = Indeterminate ? = Not Applicable
ASCI1 Time Constant High Register (I/O Address: 1DH) (Z8S180/L180-Class Processors
Only)
Bit
R/W R/W
Reset
Note: R = Read W = Write X = Indeterminate ? = Not Applicable
UM005004-0918
7 6 5
R/W R/W
0 0 0
7 6 5
R/W R/W
0 0 0
Modem Control Signals
ASCI channel 0 has CTS0, DCD0 and RTS0 external modem control
signals. ASCI channel 1 has a CTS1 modem control signal which is
multiplexed with Clocked Serial Receive Data (RXS).
CTS0: Clear to Send 0 (Input)
The CTS0 input allows external control (start/stop) of ASCI channel 0
transmit operations. When CTS0 is High, the channel 0 TDRE bit is held
at whether or not the TDR0 (Transmit Data Register) is full or empty.
0
When CTS0 is Low, TDRE reflects the state of TDR0. The actual
transmit operation is not disabled by CT High, only TDRE is inhibited:
DCD0: Data Carrier Detect 0 (Input)
The DCD0 input allows external control (start/stop) of ASCI channel 0
receive operations. When DCD0 is High, the channel 0 RDRF bit is held
at 0 whether or not the RDR0, (Receive Data Register) is full or empty.
4 3
R/W R/W R/W
0 0
4 3
R/W R/W R/W
0 0
2 1 0
R/W R/W
0 0 0
2 1 0
R/W R/W
0 0 0
