Bit
Position Bit/Field R/W
5
TE
4
CKA1D
3
MPBR/
EFR
Value
Description
R/W
Transmitter Enable — When TE is set to 1, the ASCI
transmitter is enabled. When TE is reset to 0, the
transmitter is disabled and any transmit operation in
progress is interrupted. However, the TDRE flag is not
reset and the previous contents of TDRE are held. TE is
cleared to 0 in IOSTOP mode, and during RESET.
R/W
CKA1 Clock Disable — When CKA1D is set to 1, the
multiplexed CKA1/
function. When CKA1 D is 0, the pin is used as CKA1, an
external data dock input/output for channel 1
R/W
Multiprocessor Bit Receive/Error Flag Reset — When
multiprocessor mode is enabled (MP in CNTLB is 1),
MPBR, when read, contains the value of the MPB bit for
the last receive operation. When written to 0, the EFR
function is selected to reset all error flags (OVRN, FE and
PE) to 0. MPBR/EFR is undefined during RESET.
Family MPU User Manual
TEND0
pin is used for the
UM005004-0918
Z8018x
129
TEND0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z8018 Series and is the answer not in the manual?

Questions and answers

Sam Sawyer
January 25, 2025

are there a timing diagrams for PUSH and POP instructions?

1 comments:
Mr. Anderson
May 14, 2025

The timing diagrams for the PUSH and POP instructions for the ZiLOG Z8018 Series are as follows:

POP Instruction (e.g., POP IX or POP IY):
- Machine Cycle 1 (MC1): Fetch POP opcode.
- Machine Cycle 2 (MC2): Fetch address code.
- Machine Cycle 3 (MC3): Read from memory at SP (Stack Pointer); data goes to low byte (e.g., IXL or IYL).
- Machine Cycle 4 (MC4): Read from memory at SP+1; data goes to high byte (e.g., IXH or IYH).

PUSH Instruction (e.g., PUSH IX or PUSH IY):
- Machine Cycle 1 (MC1): Fetch PUSH opcode.
- Machine Cycle 2 (MC2): Fetch address code.
- Machine Cycle 3 (MC3): Decrement SP by 1 and write high byte (e.g., IXH or IYH) to memory at SP.
- Machine Cycle 4 (MC4): Decrement SP by 1 and write low byte (e.g., IXL or IYL) to memory at SP.

Each machine cycle includes three T-states (T1, T2, T3), and memory control signals (such as MREQ, RD, WR) are active as needed during these cycles.
