Bit
Position Bit/Field R/W
– –
2 0 MOD2 0 R/W
Value Description
ASCI Data Format Mode 2, 1, 0 — These bits program
the ASCI data format as follows.
MOD2
0: 7 bit data
1: 8 bit data
MOD1
0: No parity
1: Parity enabled
MOD0
0: 1 stop bit
1: 2 stop bits
The data formats available based on all combinations of
MOD2, MOD1 and MOD0 are described in Table 17.
