Table 17.
Data Formats
MOD2
MOD1
MOD0
0
0
0
0
0
1
0
1
0
0
1
1
1
0
0
1
0
1
1
1
0
1
1
1
ASCI Control Register B0, 1 (CNTLB0, 1)
Each ASCI channel control register B configures multiprocessor mode,
parity and baud rate selection.
Family MPU User Manual
Data Format
Start + 7 bit data + 1 stop
Start + 7 bit date + 2 Stop
Start + 7 bit data + parity + 1 stop
Start + 7 bit data + parity + 2 stop
Start + 8 bit data + 1 stop
Start + 8 bit data + 2 stop
Start + 8 bit data + parity + 1 stop
Start + 8 bit date + parity + 2 stop
Z8018x
131
UM005004-0918
Advertisement
Table of Contents
Need help?
Do you have a question about the Z8018 Series and is the answer not in the manual?
Questions and answers
are there a timing diagrams for PUSH and POP instructions?
The timing diagrams for the PUSH and POP instructions for the ZiLOG Z8018 Series are as follows:
POP Instruction (e.g., POP IX or POP IY):
- Machine Cycle 1 (MC1): Fetch POP opcode.
- Machine Cycle 2 (MC2): Fetch address code.
- Machine Cycle 3 (MC3): Read from memory at SP (Stack Pointer); data goes to low byte (e.g., IXL or IYL).
- Machine Cycle 4 (MC4): Read from memory at SP+1; data goes to high byte (e.g., IXH or IYH).
PUSH Instruction (e.g., PUSH IX or PUSH IY):
- Machine Cycle 1 (MC1): Fetch PUSH opcode.
- Machine Cycle 2 (MC2): Fetch address code.
- Machine Cycle 3 (MC3): Decrement SP by 1 and write high byte (e.g., IXH or IYH) to memory at SP.
- Machine Cycle 4 (MC4): Decrement SP by 1 and write low byte (e.g., IXL or IYL) to memory at SP.
Each machine cycle includes three T-states (T1, T2, T3), and memory control signals (such as MREQ, RD, WR) are active as needed during these cycles.
