ZiLOG Z86C5000ZEM Quick Start Manual

HARDWARE FEATURES
Supported Products
Packages Emulation
18-Pin DIP Z86C03/06/09/
16/19, Z86E03/06
20-Pin DIP N/A
18-Pin SOIC N/A
20-Pin SOIC N/A
20-Pin SSOP N/A
28-Pin DIP Z86C30/31/233
40-Pin DIP Z86C40/90/243
44-Pin PLCC N/A
44-Pin QFP N/A
Notes:
[1] E03/06: With optional, separately purchased adapter, Z86E0601ZDP.
[2] With optional, separately purchased adapter, Z86E0700ZDP.
[3] With optional, separately purchased adapter, Z8671701ZDP.
[4] With optional, separately purchased adapter, Z8671701ZDS.
[5] With optional, separately purchased adapter, Z8671701ZDH.
[6] To emulate Z86233, select Z86C30 with 8 KB of ROM.
[7] To emulate Z86243, select Z86C40 with 8 KB of ROM.
[8] With optional, separately purchased adapter, Z86E4001ZDV.
[9] With optional, separately purchased adapter, Z86E4001ZDF.
GENERAL DESCRIPTION
The Z86C5000ZEM is a member of Zilog's family of
ICEBOX in-circuit emulators providing support for the
Consumer Controller Processor (CCP
Zilog's in-circuit emulators are interactive, Windows-based
development tools, providing a real-time environment for
emulation and debugging.
The emulator provides essential timing and I/O circuitry to
simplify user emulation of the prototype hardware and
software product.
Programming Notes
Z86E04/07/08
Z86E03/06 [1]
Z86717 [3]
Z86E04/07/08 [2]
Z86E03/06 [1]
Z86717 [4]
Z86717 [5]
Z86E30/31 [6]
Z86E40 [7]
Z86E40 [8]
Z86E40 [9]
™
) microcontrollers.
S
UPPOR T PRODUCT
Z86C5000ZEM
ICEBOX ™ Z8 ® F
AMILY
I -C E
N IRCUIT MULATOR
Real-Time Emulation
ICEBOX Emulator Provides In-Circuit Program
Debug Emulation
Windows-Based User Interface
Z8 GUI Emulator Software
Bit-Programmable I/O Ports for Digital Input/Output
Functions
RS-232 Connector
One-Time Programmable (OTP) Option
HP-16500 Logic Analysis System Interface Connector
Data entering, program debugging, and OTP program-
ming are performed by the monitor ROM and the host
package, which communicates through RS-232C serial
interface. The user program can be downloaded directly
from the host computer through the RS-232C connector.
User code may be executed through debugging com-
mands in the monitor.
The Z86C5000ZEM emulator can be connected to
a serial port (COM1, COM2, COM3, and COM4) of the host
computer and uses Graphical User Interface (GUI)
software.
Z86C5000ZEM
CP95DZ80305
–C50
59
