1.2

Terminology and abbreviations

◗
S5 System
◗
S5 console 4 position
(abbreviation: console)
◗
S5 console plate 4 position
(abbreviation: console plate)
◗
S5 electronics and power pack
(abbreviation: E/P pack)
◗
S5 sensor module
◗
S5 mast retaining flange, left
◗
S5 mast retaining flange, right
◗
S5 mast system (complete)
◗
S5 telescope mast with infusion rack
(abbreviation: telescope mast)
◗
S5 telescope mast, movable with
infusion rack
(abbreviation: movable mast)
◗
S5 crossbar for movable mast 4 position
(abbreviation: crossbar for movable
mast)
◗
S5 horizontal mast 4 position
(abbreviation: horizontal mast)
SM-5811-0000.01 ENG
Stöckert S5 System, modular heart-lung-machine
Contains the electronic / power supply pack with the fans
and accumulators for the emergency power supply
4 console casters with 4 parking brakes
Located on the console:
– Supports 4 pump housings or units
– With mast retaining flanges (for supporting the push
bars and telescope masts)
– With push bars (left and right)
– With crossbar on the back for the movable mast
The electronics / and power pack is located inside the
console. The E/P pack comprises the power-supply
components (including the emergency power supply), the
system connection panel and the necessary sensor
modules.
S5 power supply module
S5 UPS module
S5 DC/DC module
S5 battery discharger
The sensor module measures all the recorded values (such
as the temperature from a temperature sensor). The values
are shown on the corresponding displet (e.g. Temperature
1) via the CAN bus.
Side components for supporting the sliding T-bar handles
and telescopic masts
Comprises:
– Two vertical telescope masts
– One movable telescope mast
– Push bars (left and right)
– Horizontal mast
– Crossbar for movable mast
Fixed telescope mast
with 4-arm bottle holder
Movable telescope mast with 4-arm bottle holder
Permanently mounted on the back of the console for
supporting the movable telescope mast
With 2 mast retainers (left and right) for attachment to the
vertical masts
S5 System • Introduction
1.3
