SORIN GROUP S5 System Service Instructions Manual page 31

Item name
57 Socket 7-9
58 Socket 10-12
59 Socket for multipoint connector
60 Sensor module for bubble detector
61 Level sensor module
62 Pressure sensor module
63 Cardioplegia sensor module
64 Temperature sensor module
65 Interface module
66 APC sensor module (optional)
67 Blank module
SM-5811-0000.01 ENG
Operation
On the right hand side of the E/P pack
Connecting pumps and devices (e.g. system panel)
On the left hand side of the E/P pack
Connecting pumps and devices (e.g. system panel)
On the right hand side of the E/P pack
Connecting the multipoint connector
Connecting the bubble sensor
Connecting the sensor for the level monitor
Connecting the sensors for pressure control 1 and 2
Connection for bubble sensor and pressure transducer for
cardioplegia control
Connecting the temperature probes to the temperature
monitor
Connecting for data transfer of external devices
(e.g. Data Management System, abbreviation: DMS)
Connects the bubble sensor of the Air Purge Control
Covering unused slots
S5 System • System description
3.11
