SORIN GROUP S5 System Service Instructions Manual page 181

Fast clamp connector
Washer MRP 150
Connector MRP 150
Computer board
Keys and LEDs circuit board (MRP 150 and MRP 85/1) HKD 0327
Keys and LEDs circuit board (MRP 85/2)
Inverter (for LED display)
Heat sink MRP 85
Motor controller MRP85/x (L-shaped circuit board)
Motor power amplifier MRP 85/x (L-shaped circuit
board)
Motor controller (all except MRP 85/x)
Motor output stage (all except MRP 85/x)
Circuit board for fan control panel (complete)
Motor power amplifier (complete)
Hexagon head screw, DIN 933 M6x16
Leaf spring
Locating pin
Guide piece MRP 150
Socket head screw, DIN 912, M3x4
Socket head screw, DIN 912, M3x6
Socket head screw, DIN 912, M3x8
Socket head screw, DIN 912, M3x12
Socket head screw, DIN 912, M4x6
Socket head screw, DIN 912, M4x8
Spring washer, DIN 127, B §
Washer DIN 125 A 3.2
Line filter
Fan screen EMC 60x60
Distance plate for fan
Push rivet (d3.5/5.5 – 6.5 mm)
Fan
Double holder MRP 85 (MRP 85/2 adapter)
Holder MRP 150/85 (short adapter)
Cap
SM-5811-0000.01 ENG
43-42-60
10-88-17
10-88-16
HKR 0325 90-305-620
90-305-640
HKD 0327 90-505-640
LXM1617-05-6x 93-146-026
10-88-77
HMR 0403 90-305-710
HME 0402 90-305-700
HMS 0409 90-305-770
HMF 0408 90-305-760
HDM 0503 90-105-850
10-88-10
71-110-051
10-88-13
10-88-44
10-88-43
71-115-000
71-115-001
71-115-007
71-115-009
71-115-010
71-115-011
71-120-526
71-120-501
FN332Z-10-05 96-401-012
10-84-42
10-84-43
96-520-063
Pabst 614, 24 V 96-406-031
10-88-68
10-88-69
10-88-71
S5 System • Appendix
7.33
