Faults in the sensor modules or sensors

Display in system menu
Module defective
Module/sensor defective
Check level sensor
Receive signal too strong
Receive signal too strong
37° reference inexact
SM-5811-0000.01 ENG
S5 System • Fault messages and troubleshooting
Description
➜
possible cause/effect
◗
Steps to be taken
➜
There is a module or sensor defect. (The display of the
relevant icon indicates the corresponding monitoring
function. In this case: level monitor).
◗
Replace corresponding sensor module or sensor.
➜
There is a level sensor contact failure.
◗
Check that the level sensor is correctly seated (e.g. on the
reservoir/oxygenator).
◗
Check the metal contacts of the level sensor.
◗
Replace corresponding sensor module or sensor.
➜
The signal of the bubble sensor is too strong and cannot be
processed or the sensor is not connected.
◗
Check that the bubble sensor is correctly seated.
◗
Replace corresponding sensor module or sensor.
➜
The reference voltage of the temperature module is outside
the permitted tolerance range.
◗
Replace corresponding sensor module or sensor.
